Specifications
Supply Ability :
5000000000 pieces/year
Dimensions :
64.70mm x 117.94mm x 1.75mm
Interface :
27Pin, 4 LANE MIPI
Model Number :
KWH050ST26-F01
Product Name :
5 Inch LCD Display Module 720x1280 720p TFT MIPI LCD Panel With ILI9881 Driver IC
Resolution :
720 * 1280
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Controller Ic :
ILI9881
Color :
Color
Display Type :
5Inch IPS TFT LCD Panel
MOQ :
1 piece
Payment Terms :
T/T,L/C,Credit card,Cash
Packaging Details :
Tray + Inner Box + Carton
Touch Screen :
Without (Optional with touch panel)
Operating Temperature :
-20°C to 70°C
Brand Name :
Formike
Display Size :
5-inch
Supply Voltage :
3.3V
Viewing Angle :
All
Place of Origin :
China
Description

5 Inch LCD Display Module 720x1280 720p TFT MIPI LCD Panel With ILI9881 Driver IC

5 Inch 720x1280 720p TFT MIPI LCD Display Module LCD Panel With ILI9881 Driver IC

Product Name 5 Inch LCD Display Module 720x1280 720p TFT MIPI LCD Panel With ILI9881 Driver IC
LCD Size 5 Inch TFT LCD Display Module
Display Mode IPS
Resolution 720x1280
Outline Dimension (mm) 64.70x117.94x1.75
Active Area (mm) 62.10x110.40
Dot pitch (mm) 0.08625x0.08625
Viewing Direction All
Interface MIPI Interface, 27 Pin
Driver IC ILI9881
Brightness (Cd/m2) 250
Contrast Ratio 800:1
Backlight 12 White LEDs

Backlight Supply

(Current/Voltage)

 40mA 19.2V
Touch Screen Without(Optional with capacitive touch panel)

* KWH050ST26-F01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 720x1280 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
