NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
Specifications
MOQ :
1 piece
Dimensions :
80.70mm x 141.84mm x 3.67mm
Interface :
45Pin, 16 BIT RGB
Payment Terms :
T/T,L/C,Credit card,Cash
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Product Name :
480x854 FWVGA LCD Display 5 Inch TFT Touch Screen Module
Resolution :
480x854
Controller Ic :
NT35510
Color :
Color
Display Type :
5Inch IPS TFT LCD Screen
Supply Ability :
5000000000 pieces/year
Packaging Details :
Tray + Inner Box + Carton
Operating Temperature :
-20°C to 70°C
Brand Name :
Formike
Model Number :
KWH050ST20-C02
Display Size :
5 inch
Supply Voltage :
3.3V
Viewing Angle :
All
Place of Origin :
China
Touch Screen :
With capacitive touch screen
Description

480x854 FWVGA LCD Display 5 Inch TFT Touch Screen Module

NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854

Product Name 480x854 FWVGA LCD Display 5 Inch TFT Touch Screen Module
LCD Size 5 Inch TFT LCD Display Module
Display Mode IPS
Resolution 480x854
Outline Dimension (mm) 80.70x141.84x3.67
Active Area (mm) 62.064x110.4222
Dot pitch (mm) 0.1293x0.1293
Viewing Direction All
Interface 16 BIT RGB Interface, 45 Pin
Color Depth 16M
Brightness (Cd/m2) 400
Contrast Ratio 800:1
Backlight 12 White LED

Backlight Supply

(Current/Voltage)

 40mA 19.2V
Touch Screen With Capacitive Touch Screen Panel

* KWH050ST20-C02 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 480x854 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854NT35510 FWVGA TFT LCD Touch Screen Display Module 5 Inch For Car 480x854
