Specifications
Backlight :
LED
Display Mode :
STN
Supply Ability :
5000000000 pieces/year
Packaging Details :
Tray + Inner Box + Carton
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Product Name :
16x2 LCD Display Module 1602 Screen LCD COB With 16 Pin Pinout
Viewing Angle :
6 O'clock
Operating Temperature :
-20°C to 70°C
Model Number :
WC1602B5
Dimensions :
84mm * 44mm * 13mm
Operating Voltage :
3.3V / 5V
Display Type :
LCD Character Module
Interface :
16-Pin, 4-bit or 8-bit 6800 MPU
Controller :
ST7066U or AIP31066
Place of Origin :
China
Display format :
16character*2 line
MOQ :
1 piece
Payment Terms :
T/T,L/C,Credit card,Cash
Brand Name :
Formike
Backlight Color :
Usually Y-G or Blue or Gray
Description

16x2 LCD Display Module 1602 Screen LCD COB With 16 Pin Pinout

COB 2x16 LCD Display I2C Module 1602 Screen With 16 Pin Pinout

Product Specification
LCD Name 16x2 LCD Display Module 1602 Screen LCD COB With 16 Pin Pinout
Display Format 16character*2 line
Module Size 80.0mm×36.0mm×12.5mm
View Area 64.5mm×16.0mm
Character Size 2.96mm×5.53mm
Character Pitch 3.55mm×5.98mm
IC AIP31066 or Eqv (Defualt English / Japan Font)
Interface 16 Pin, 4-bit or 8-bit 6800 MPU interface enabled
Driving Method 1/16 Duty, 1/5 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WC1602B5SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WC1602B5SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WC1602B5SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WC1602B5SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WC1602B5SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WC1602B5SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
