ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
ASME SA213 T12 Low Embedded Fin Pipe Tube For Heat Exchangers Customised
Specifications
Brand Name :
YUHONG
Model Number :
High Frequency weld fin tube, Welding fin tube, Fin Tube, Finned Tube, Solid Fin tube, HFW fin tube, Serrated Fin Tube
Certification :
ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Place of Origin :
China,Korea
MOQ :
1PC
Price :
1--10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 tons/month
Delivery Time :
5---75 days
Packaging Details :
Bundle + Cap , Ply wooden case
Base Tube Material :
T12
Standard :
ASME SA213 , ASTM A213
Fin Material :
Stainless steel
Fin Type :
High Frequency Welding Serrated Fin Tube
Length :
Max.: 34m/pc
Application :
Fired Furnace, Fired Heater, Convection Tube, Radiant Tube, Raffinate, Tube Coil, Coils
Description
ASME SA213 T12 High Frequency Welding Fin Tube For Power Plants
Product Specifications
Attribute Value
Base Tube Material T12
Standard ASME SA213, ASTM A213
Fin Material Stainless steel
Fin Type High Frequency Welding Serrated Fin Tube
Length Max.: 34m/pc
Application Fired Furnace, Fired Heater, Convection Tube, Radiant Tube, Raffinate, Tube Coil, Coils
Product Description
The "T12" designation refers to Grade T12, a low-alloy steel containing 1.25% chromium and 0.5% molybdenum, offering excellent high-temperature strength.
Provides superior resistance to creep and oxidation, making it ideal for demanding power plant applications.
Chromium and molybdenum content enhances corrosion resistance in high-temperature environments.
Serrated fins increase surface area for optimal heat dissipation or absorption.
High-frequency welding process ensures cost-effectiveness and production efficiency.
Chemical Composition
Grade Cr Mo C Fe
ASME SA213 T12 0.8–1.25% 0.44–0.65% 0.05–0.15% Balance
Mechanical Properties
Grade Tensile Strength Yield Strength Elongation Hardness Operating Temperature Range
ASME SA213 T12 415–585 MPa (60–85 ksi) ≥ 205 MPa (30 ksi) ≥ 24% ≤ 85 HRB Up to 560°C (1040°F)
Applications
Heat Exchanger Units
Boilers
Waste Heat Recovery
Flue Gas Desulfurization
Superheaters & Reheaters
Heat Transfer Systems
Cooling Systems
Steam Generators
Desalination Plants
Air Heaters
Chilled Water Systems
