HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
HFW Solid Aluminum Welded High Fin Tube For Copper Pipe TP304
Specifications
Brand Name :
YUHONG
Model Number :
ASME SA213 T12
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
CHINA
MOQ :
Depend the size of finned tubes
Price :
20-10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
1000 tons/month
Delivery Time :
35-60 days
Packaging Details :
Ply-wooden Case With Iron Frame
Product :
Finned Tube
Type :
HFW / Solid Finned Tubes
Tubes :
ASME SA213 T12
Fins :
TP304
Length :
According to clients' need
Size and details :
According to clients' need
Packing :
Ply-wooden Case With Iron Frame
Use :
Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc
Description
Power Generation Solid Welded Fin Tube Pipe ASME SA213 Material T12
Product Specifications
Attribute Value
Product Finned Tube
Type HFW / Solid Finned Tubes
Tubes ASME SA213 T12
Fins TP304
Length Custom according to requirements
Size and details Custom according to requirements
Packing Ply-wooden Case With Iron Frame
Use Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc
Product Description

Solid Welded Finned Tubes ASME SA213 Material T12 for Power Generation

ASME SA213/ASTM A213 covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes. T12 material offers high-temperature strength, excellent corrosion resistance, weldability and formability. These tubes are essential for high-temperature and high-pressure applications, providing durability and reliability in demanding environments.

Chemical Composition (%)
Grade C Mn P S Si Cr Mo
T12 0.05-0.15 0.30-0.61 0.025 0.025 0.50 0.80-1.25 0.44-0.65
Mechanical Properties
Grade Tensile Strength, min Yield Strength (0.2% Offset, min) Tempering Temperature, min
T12 60ksi (415 MPa) 32ksi (220 MPa) 1200-1350°F [650-730°C]
Additional Properties
T12 Elongation in 2 in.: 30% Hardness: 163HBW/170HV Rockwell: 85HRB
Definition

Solid fin tubes, also called high frequency welded fin tubes, are specialized heat exchanger tubes with fins integrally bonded to the outer surface. These fins enhance heat transfer efficiency by increasing the surface area in contact with the surrounding medium.

Key Advantages
  • Increased surface area improves heat transfer efficiency
  • Enhanced corrosion and wear resistance with low contact thermal resistance
  • High stability and anti-ash ability with excellent stiffness and seismic performance
  • Superior weld microstructure due to high welding speed and strong self-cooling effect
  • Robust construction resistant to mechanical damage
Applications
  • Boilers and Heat Exchangers
  • Heating and Cooling Systems
  • Power Generation
  • Chemical Processing
  • HVAC Systems
  • Marine Applications
