PRODUCT DESCRIPTION

High Precision 4 Axis CNC Vertical Machining Center DM-1060

The 4 Axis version of DM-1060 is a high speed, high rigidity and high precision CNC machining center. The excellent rigidity provides a extremly stability for processing. The column of this machine is a double-wall structure design, which greatly improves the rigidity for the machine. In order to prevent the Z-axis from colliding with the column when moving fast, we designed a guide rail between the Z-axis counterweight and the column in this machine to prevent such situations. Our machine is made of FC-30 material to ensure the service life and accuracy. The range of revolutions of the spindle is 8000RPM. The high speed revolutions provides good efficiency for processing. The high rigidity bellows direct coupling is also equiped in this machine, each ball screw and servo motor uses direct connection type.

Main Technical Parameters

Standard Configuration for DM Series

1. Full Cover shield /

2. Self-lubrication system /

3. Working lights /

4. Warning lights /

5. Working condition warning lights /

6. M30 Self-powered electrical shutoff system /

7. Clean air gun/ Water Tank / Transformer /

8. Spindle air curtain and dust control system /

9. Electric box heat exchanger/

10.Worktable cleaning water gun

Optional Configuration for DM Series

1. NC rotary table (4 Axis) /

2. CTS /

3. Tool detection system /

4. Automatic tool length measurement and damage detector /

5. Three axis optical ruler /

6,.Disc type oil-water separator /

7. Crawler iron filings carrier /

8. AJO

Product Details

FAQ

1. Is it all right to make customer's own brand name?

A: yes. we are available with OEM

2. Are you a manufactuer or trading company?

A:We are the manufacturer

3. Can you do the design for us?

A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?

A: FOB shenzhen.

5. What's your payment term?

A: T/T OR L/C at sight.
