Shockproof 4 Axis CNC Machining Center VMC 1375 8000r/Min Stable
Shockproof 4 Axis CNC Machining Center VMC 1375 8000r/Min Stable
Specifications
Brand Name :
Li Zhun
Model Number :
VMC-1375
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10000 per year
Delivery Time :
30-45 work days
Packaging Details :
Wooden Box
Certification :
SGS
Condition :
New
Warranty :
1 Year
Type :
Vertical
Axis :
4
Max Load of Work Table :
1000 kg
Spindle Speed :
10000 RPM
Description

High Speed 4 Axis CNC Vertical Machining Center VMC 1375 High Precision

PRODUCT DESCRIPTION

The 4 Axis CNC Vertical Machining Center VMC-1375 is a a high speed, high precision and high rigidity machine. The size of the worktable is 710*1400, which can provides high convenience for processing big or complex parts. The whole fuselage and base are made of highly rigid materials, which will not be deformed during processing. the machine is also equipped with high rotation spindle, the highest rotation can reach 8000rpm, wihch can ensure the processing efficiency. The spindle nose adopts shockproof material, which can absorb vibration and avoid the precision error of machining surface caused by vibration. The machine also uses oil-water separation design, which can not only prolong the service life of the chip fluid, but also reduce the cost and meet the requirements of environmental protection requirement.

Main Technical Parameters

ITEM MODELS VMC1375
WORKTABLE (WIDTH*LENGTH) mm 710*1400
DISTANCE BETWEEN T SLOTS mm 5-18*152.5
MAX LOAD BEARING OF WORKTABLE kg 1000
X/Y/Z AXIS TRAVEL mm 1300/750/720
4-AXIS /
DISTANCE FROM SPINDLE NOSE TOWORKBENCH mm 150-800
SPINDLE HOLE TAPER TB50
SPINDLE SPEED RANGE r/min 8000
TRANSMISSION OF SPINDLE BOX BELT/DIRECT BELT/DIRECT
SPINDLE MOTOR POWER kW 15
X/Y/Z RAPID FEED SPEED m/min 16/16/16
MAX CUTTING FEED SPEED mm/min 1-5000

TOOLS MAGAZINE CAPACITY		 pcs 24
FULL TOOLS MAX TOOL DIAMETER mm 240
MAX.TOOLS ALLOWABLE WEIGHT kg 15
MAX.TOOLS ALLOWABLE LENGTH mm 305
X/Y/Z POSITION ACCURACY mm 0.008
X/Y/Z RE-POSITION ACCURACY mm 0.005
MACHINE DIMENSION mm 4535*3050*3100
MACHINE WEIGHT kg 9000

Standard Configuration for VMC Series

1. Full Cover shield

2. Self-lubrication system

3. Working lights

4. Warning lights

5. Working condition warning lights

6. Self-powered electrical shutoff system

7. Clean air gun/ Water Tank / Transformer

8. Spindle air curtain and dust control system

9. 10000 RPM spindle

10.Worktable cleaning water gun

Optional Configuration for VMC Series

1. 24 disc manipulator tool magazine

2. Crawler chips remover

3. NC rotary table (4 Axis)

4. CTS

5. Tool detection system

6,. AJO

7. 12000 & 15000 RPM Direct connection spindle

8. Oil mist purifier
