8000 RPM 4 Axis CNC Machining Center VMC1475 Multiscene Practical
8000 RPM 4 Axis CNC Machining Center VMC1475 Multiscene Practical
Specifications
Brand Name :
LiZhun
Model Number :
VMC1475
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10000 per years
Delivery Time :
30-45work days
Packaging Details :
Wooden box
Certification :
SGS
Warranty :
1 Year
Condition :
New
Type :
Vertical
Spindle :
Taiwan 8000rpm spindle
Spindle taper :
BT50
Product name :
4 axis Vertical CNC Machining center VMC1475
Description

High Speed precision Vertical CNC Machining Center VNC1475 8000rpm

Product description

VMC series is a flexible series that can process many industries, such as mold industry, hardware industry, communication industry, military, 5g industry, etc

Main technical parameters

ITEM MODELS→ VMC1475 VMC1580

WORKTABLE (WIDTH*LENGTH)		 mm 700*1500 800*1700

DISTANCE BETWEEN T SLOTS		 mm 5-18*152.5 5-22*135

MAX LOAD BEARING OF WORKTABLE		 kg 1000 1500

X/Y/Z AXIS TRAVEL		 mm 1400/750/650 1500/800/700

DISTANCE FROM SPINDLE NOSE TOWORKBENCH		 mm 170-780 170-780

SPINDLE HOLE TAPER		 TB50 TB50

SPINDLE SPEED RANGE		 r/min 8000 8000

TRANSMISSION OF SPINDLE BOX		 BELT/DIRECT BELT/DIRECT BELT/DIRECT

SPINDLE MOTOR POWER		 kW 15 15

X/Y/Z RAPID FEED SPEED		 m/min 24*24*18 18*18*18

MAX CUTTING FEED SPEED		 mm/min 1-10000 1-10000

TOOLS MAGAZINE CAPACITY		 pcs 24 24

FULL TOOLS MAX TOOL DIAMETER		 mm 240 240

MAX.TOOLS ALLOWABLE WEIGHT		 kg 15 15

MAX.TOOLS ALLOWABLE LENGTH		 mm 305 305

X/Y/Z POSITION ACCURACY		 mm 0.008 0.008

X/Y/Z RE-POSITION ACCURACY		 mm 0.005 0.005

MACHINE DIMENSION		 mm 4535*3050*3100 4110*2740*2900

MACHINE WEIGHT		 kg 11800 12800

8000 RPM 4 Axis CNC Machining Center VMC1475 Multiscene Practical

Main configuration:

(1) Resin sand castings are tempered and aging treated.
(2) Taiwan Shangyin ball screw and precision screw lock nut;
(3) Taiwan Shangyin roller linear guide
(4) Taiwan BT40 spindle unit (10000 rpm) with ring spray, optional central water outlet and 12000 rpm direct connection.
(5) Pressurized cylinders and timing pulleys for Taiwan.
(6) Screw NSK bearing
(7) X, Y, Z three-axis stainless steel guide rail internal protection
(8) Standard configuration Taiwan AIMACH24T manipulator disc tool magazine
(9) Equipped with automatic lubrication system, cooling, spindle air blowing, warning lights, explosion-proof lighting, etc.
(10) The standard configuration is all-metal outer protection, and the economical semi-protection is optional.
(11) The system comes standard with fanuc system, Siemens, Mitsubishi, and supports optional fifth-axis.
