15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
15KW VSD Air cooling oil inject screw compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGCD-15D C VP
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
6300
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.8-1.3Bar
Cooling type :
Air cooling
Driven type :
Direct driven
Description
AIRERA | 15kW Industrial VSD Oil-Injected Screw Compressor
Steady Power, Intelligent Efficiency — The Cornerstone for Mid-Scale Production
The AIRERA 15kW Series is the ultimate energy-saving solution for medium-sized manufacturing enterprises seeking maximum uptime and minimal operational costs. Acting as the heart of your production line, this model integrates advanced Variable Speed Drive (VSD) technology to precisely match air output between 20% and 100% of demand. By eliminating wasteful unloading cycles, it achieves energy savings of over 30% compared to standard units, making it an ideal choice for green manufacturing.
Advantages of AGCD VSD Oil-Inject Air Screw Compressor
  • Upgraded high-efficiency screw compressor heads for greater airflow

    By selecting low-speed screw rotors and the most suitable motors, and pairing them with main units optimized for specific speeds, we ensure that each rotor operates at its optimal speed, achieving the best possible energy efficiency ratio.

    15KW VSD Air cooling oil inject screw compressor
  • Multi-touch color controller for simple and convenient operation and monitoring
15KW VSD Air cooling oil inject screw compressor
  • The more efficient SF 1.2 IP55 VSD motor complies with IE5 and MEPS standards and meets the national Class 1 energy efficiency standards

15KW VSD Air cooling oil inject screw compressor
Technical Specifications - 15KW VSD Air Cooling Compressor
ITEM UNIT MODEL AGCD-15 VP
Free air delivery m³/min 0.6-2.3 | 0.54-2.05 | 0.5-1.65
Max. working pressure MPa 0.8 ~1.3
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ ≤45
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤70
Residual oil content ppm ≤2
Drive rotor speed rpm 800~3000
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 6300
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77 ~ 1.43
Lubricating water volume L 10
Compressed air outlet connection
G1
Dimension - L mm 1060
Dimension - W mm 700
Dimension - H mm 1200
Net Weight kg 370
Motor - Model
YPM132M30-15
Motor - Speed rpm 800~3000
Motor - Rated Power KW 15
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE3
Motor - Startup mode
Frequency conversion starting
Motor - Voltage V 380(Special on request)
Motor - Frequency Hz 40-150(Special on request)
Motor - Rated current A 25.2
Motor - Weight of motor kg 70
15KW VSD Air cooling oil inject screw compressor
AIRERA 15kW VP Screw Air Compressor: Frequently Asked Questions (FAQ)
How "grid-friendly" is VSD technology for the 15kW power range?
Very friendly. While a fixed-speed 15kW unit’s start-up current can be several times its running current, causing spikes, AIRERA VSD features soft-start capability. The current ramps up smoothly from zero, preventing instantaneous voltage fluctuations. This protects both your transformer and other sensitive electronic equipment on the same grid.
Is the 15kW air-cooling system sufficient for continuous 24/7 operation?
Absolutely. The AIRERA 15kW model features an enhanced cooling flow design. Utilizing a high-volume, low-noise axial fan and high-efficiency finned coolers, it ensures that lubricant temperatures stay within the ideal 80°C–90°C range, even during peak summer temperatures in the factory, preventing any heat-related shutdowns.
What is the ROI of a 15kW VSD model compared to a fixed-speed model?
Although the initial cost of a VSD unit is higher, the payback is rapid. A 15kW unit under typical industrial loads can save approximately 15,000–25,000 kWh per year (depending on operating hours). Typically, within 8 to 14 months, the energy savings alone cover the price premium of the VSD, turning energy costs into profit for the remainder of the machine’s life.
