30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
30KW VSD Direct driven oil inject screw compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGCD-30D C VP
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
9200
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.8-1.3Bar
Cooling type :
Air cooling
Driven type :
Direct driven
Description
AIRERA | 30kW VSD Direct Driven Oil-Injected Screw Compressor
Peak Efficiency, Direct Drive — The Sustainable Power Core for Large-Scale Production
The AIRERA 30kW Series is an energy-efficiency benchmark built for high-load, long-operating-hour industrial environments. By integrating 1:1 Direct Drive technology with an advanced Variable Speed Drive (VSD) system, this unit eliminates the transmission losses and unloading waste common in mid-to-large-scale compressors. Whether supporting complex automated lines or heavy manufacturing, it delivers exceptionally stable and economical compressed air, reducing energy costs by over 35% compared to traditional belt-driven models.
Advantages of AGCD VSD Oil-Inject Air Screw Compressor
  • With a wider frequency modulation range of 30–200 Hz, it is 15–35% more energy-efficient than most 300–100 Hz compressors on the market

    Next-generation control system: We employ dual-inverter technology, retaining the original motor inverter features while also incorporating an inverter-controlled cooling fan for the main unit. This dual-inverter approach ensures the cooling system operates in a stable state, and the modular design facilitates easy maintenance.

30KW VSD Direct driven oil inject screw compressor

  • Multi-touch color controller for simple and convenient operation and monitoring



30KW VSD Direct driven oil inject screw compressor

  • Custom air intake system that prevents dust from entering


    A three-stage filtration system removes fine particles from the air, filtering out 99.99% of impurities to ensure the quality of the air entering the unit and extend its service life
30KW VSD Direct driven oil inject screw compressor
Technical Specifications - 30KW VSD Air Cooling Compressor
ITEM UNIT MODEL AGCD-30 VP
Free air delivery m³/min 1.25-5 | 1.15-4.5 | 0.95-3.6
Max. working pressure MPa 0.8 ~1.3
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ ≤45
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤72
Residual oil content ppm ≤2
Drive rotor speed rpm 800~3000
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 9200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.88 ~ 1.43
Lubricating water volume L 30
Compressed air outlet connection
G1-1/2
Dimension - L mm 1400
Dimension - W mm 1000
Dimension - H mm 1300
Net Weight kg 740
Motor - Model
YPM160L30-30
Motor - Speed rpm 800~3000
Motor - Rated Power KW 30
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE3
Motor - Startup mode
Frequency conversion starting
Motor - Voltage V 380(Special on request)
Motor - Frequency Hz 40-150(Special on request)
Motor - Rated current A 51
Motor - Weight of motor kg 150
30KW VSD Direct driven oil inject screw compressor
AIRERA 30kW VP Screw Air Compressor: Frequently Asked Questions (FAQ)
What is the approximate air delivery of this 30kW unit? How many pneumatic tools can it support?
A 30kW VSD compressor delivers approximately $5.0-5.5text{ m}^3/text{min}$ at 0.8MPa. While the exact number of tools depends on individual air consumption, it is typically sufficient to power a medium-to-large machining workshop, a mid-scale painting line, or multiple textile production units.
Why is air-cooling recommended for high-power machines like the 30kW model?
While water-cooling is common for high power, AIRERA’s optimized air-cooling is more economical and convenient for the 30kW range. It eliminates the need for expensive cooling towers and plumbing, and removes the risks of freezing in winter or scaling in pipes. Our oversized aluminum finned radiators ensure excellent temperature control even in harsh, high-ambient conditions.
What are the benefits of VSD soft-starting for a mid-to-large motor like the 30kW?
It protects both your power grid and mechanical longevity. A 30kW motor would generate a massive current spike if started directly. VSD soft-starting allows the current to ramp up slowly from zero, preventing voltage drops that could crash other factory equipment. Simultaneously, by minimizing startup impact, the gears and bearings of the airend receive physical protection, leading to a longer service life.
