132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
132KW VSD Air cooling oil inject screw compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGCD-132D C VP
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow :
14200
Application :
Medical, Pharmaceutical, Food Processing
Working Pressure :
0.8-1.3Bar
Cooling type :
Air cooling
Driven type :
Direct driven
Description
AIRERA 132kW VSD Series: The "Power Anchor" and Energy Pioneer for Heavy Industry

Engineered as the powerhouse for major industrial hubs, the AIRERA 132kW series represents the pinnacle of industrial-grade compressed air technology. By coupling massive air delivery with precision Variable Speed Drive (VSD) control, we provide continuous, stable, and highly cost-effective power support for large-scale production lines.

Advantages of AGCD VSD Oil-Inject Air Screw Compressor

  • Upgraded high-efficiency screw compressor heads for greater airflow

By selecting low-speed screw rotors and the most suitable motors, and pairing them with main units optimized for specific speeds, we ensure that each rotor operates at its optimal speed, achieving the best possible energy efficiency ratio.

132KW VSD Air cooling oil inject screw compressor

  • Specialized Oversized Inlet Valve

· Normally closed, oversized bore, ultra-low pressure drop;

· Low failure rate, long service life;

132KW VSD Air cooling oil inject screw compressor

·Custom air intake system that prevents dust from entering

A three-stage filtration system removes fine particles from the air, filtering out 99.99% of impurities to ensure the quality of the air entering the unit and extend its service life.


132KW VSD Air cooling oil inject screw compressor

Technical Specifications - 132KW VSD Air Cooling Compressor
ITEM UNIT MODEL AGCD-132 VP
Free air delivery m³/min 5.9-23.5 | 5.3-21.0| 4.75-17.5
Max. working pressure MPa 0.8 ~1.3
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status - Temperature ℃ ≤45
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤79
Residual oil content ppm ≤2
Drive rotor speed rpm 800~3000
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 14200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.88 ~ 1.43
Lubricating water volume L 90
Compressed air outlet connection
G2-1/2
Dimension - L mm 2540
Dimension - W mm 1640
Dimension - H mm 1800
Net Weight kg 2350
Motor - Model
YPM280S30-132
Motor - Speed rpm 800~3000
Motor - Rated Power KW 132
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE3
Motor - Startup mode
Frequency conversion starting
Motor - Voltage V 380(Special on request)
Motor - Frequency Hz 50-200(Special on request)
Motor - Rated current A 224
Motor - Weight of motor kg 1010

132KW VSD Air cooling oil inject screw compressor

AIRERA 132kW VP Screw Air Compressor: Frequently Asked Questions (FAQ)
Since 132kW is a high-power model, is VSD technology stable at this scale?

Absolutely. AIRERA utilizes industrial-grade, heavy-duty specialized inverters with power margins designed far beyond standard requirements. For a 132kW motor, the VSD provides precise speed control and, more importantly, a "Soft Start" that keeps starting current within the rated limits. This significantly reduces stress on motor windings and the grid, extending motor mechanical life by over 30% compared to traditional Star-Delta starting.

For factories with massive air demand, what is the efficiency of the 132kW air end?

This model is equipped with AIRERA’s flagship large-diameter 5:6 profile rotor air end. Because of the large rotor diameter and low rotational speed, the volumetric efficiency is exceptionally high. At the same 132kW power input, our units typically deliver 5%-8% more air than the industry average, providing more air for your production lines without extra power costs.

Is maintenance difficult for a machine of this size?
Not at all. We employ a "User-Centric Maintenance Design." Despite its large footprint, all side panels are quickly removable. Consumables like oil separators, oil filters, and air filters are positioned for easy access.
