Description

Pepperl+Fuchs NBN3-F31K-Z8-K | M8 3mm Sensor, 2 NO, IP67

Pepperl+Fuchs NBN3-F31K-Z8-K inductive proximity sensor. M8 threaded barrel, 3mm range, 2 normally open outputs, 6-60V DC, IP67, -25°C to +70°C.

Product Overview

The Pepperl+Fuchs NBN3-F31K-Z8-K​ is a compact M8 inductive proximity sensor​ designed for space-constrained industrial applications. It features a 3 mm sensing range​ for detecting metallic objects and offers dual normally open (NO) outputs​ for flexible wiring configurations. With a wide 6-60V DC operating voltage​ and IP67 protection rating, this sensor is suitable for use in harsh environments where reliable object detection is critical.

Technical Specifications (Electrical & Functional)

Parameter

Specification

Sensor Type​

Inductive Proximity (Shielded / Flush Mount)

Output Type​

2 Normally Open (NO) Contacts​

Rated Operating Distance​

3 mm​

Assured Operating Distance​

0 ... 2.43 mm

Operating Voltage​

6 ... 60 V DC​

Switching Frequency​

0 ... 500 Hz​

Voltage Drop​

≤ 5.5 V

Switching Current​

4 ... 100 mA

Hysteresis​

Typ. 5%

Protection​

Reverse Polarity, Short-circuit (Pulsing)

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Housing​

PBT Plastic

Thread Size​

M8 x 1​

Connection​

Cage Clamp Terminal​

Wire Cross-Section​

1.5 / 2.5 mm²

Degree of Protection​

IP67​

Operating Temperature​

-25 °C ... +70 °C​

Housing Length​

31 mm

Weight​

Approx. 18 g

Mounting​

Flush Mountable

Key Features

  • Dual Output Configuration:​ Features two independent normally open (NO) contacts, providing wiring flexibility for control circuits.

  • Wide Voltage Range:​ Operates on 6-60V DC, making it compatible with a variety of industrial control systems.

  • Compact Design:​ M8 threaded barrel allows for easy installation in tight spaces where larger sensors cannot fit.

Applications

  • Position detection of small metal parts on conveyor systems

  • End-of-stroke sensing in compact pneumatic cylinders

  • Presence verification in assembly automation and packaging machinery
