6KW 10M/Min Laser Engraving Machine / Coating Line Machine
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
Specifications
Brand Name :
Osmanuv
Place of Origin :
CHINA
Delivery Time :
35-45 Working days
Model Number :
OSM-AR-1320A
Price :
Negotiable
MOQ :
1 Set
Payment Terms :
T/T,Western Union
Packaging Details :
Wooden Box
Certification :
ISO9001 And CE
Supply Ability :
According to customer's demand
Product Name :
Ar film coating machine
Color :
Computer white / Green
Size :
L:4000 mm x H:2450 mm x W:1300mm
Inside the machine width :
1650 mm
coating weight :
2-15g/m²
Total power :
6KW
Description
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
This industrial coating machine is designed for rolling various primers and topcoats with precision and reliability.
Technical Specifications
1 Suitable for rolling all types of primers and topcoats. Powered by Mitsubishi servo motor.
2 Rollers made of high-quality Japanese transparent polyurethane (PU adhesive), offering superior wear resistance. Customizable hardness (45-50 degrees) with industrial alcohol resistance. Features high-quality anti-vibration coupling, Japan NSK bearings, and Taiwan Taida frequency converter with speed control of 2-10M/min.
Roller Configuration
1 Includes 1 mirror roller and 1 grinding roller
2 Metering wheel constructed from seamless steel tube with CO² welding, tempered treatment, fine grinding surface (pulsation <0.02mm). Features 60 mesh concave plate laser engraving, direct insert connection transmission, Japan NSK bearings, and Taiwan Delta frequency converter with speed control of 2-15M/min.
3 Anti-grain wheel made from 45# seamless steel tube with CO² welding, quenching treatment, fine grinding surface (runout <0.03mm). Hard chrome plated and polished surface, direct insert connection transmission, Japan NSK bearings, and Taiwan Delta frequency converter with speed control of 2-15M/min.
4 High precision linear sliding table between coating head and frame ensures rigidity and precision. Electronic eye controls coating thickness with 0.1mm precision.
5 Emergency stop safety system with thick plate protection - coating head rises during emergency stop to reduce safety accidents.
6 PLC control panel with human-machine interface using Mitsubishi series. Features manual and automatic modes with line speed control within 0.01M precision.
6KW 10M/Min Laser Engraving Machine / Coating Line Machine
Frequently Asked Questions
Are you a trading company or manufacturer?
We are a manufacturer with independent import and export rights. Our factory is located in Guangdong, China.
How can I verify your machine quality?
We provide sample testing on our machines with video documentation. Factory visits are available. Our products are widely used in China, Southeast Asia, South America, and Europe.
What certifications do you have?
Our production follows GMP & ISO standards and our products have CE certification for export.
What is your Quality Warranty?
One year warranty with lifelong maintenance and technical support.
