Microhardness Tester with 100X and 400X Magnification for Ferrous Metals
Microhardness Tester with 100X and 400X Magnification for Ferrous Metals
Specifications
Brand Name :
UNIMETRO
Model Number :
HV-5
Place of Origin :
China
MOQ :
1
Price :
Discussible
Payment Terms :
T/T
Supply Ability :
10 per month
Delivery Time :
8 work days
Packaging Details :
Wood case
Programming :
C++ Language
Testing force :
1.96, 2.94, 4.90, 9.80, 19.6, 29.4, 49.0
Magnification of the measuring microscope :
100X, 400X
X, Y stage dimension :
100×100 mm
X,Y stage travel :
25×25 mm
Application :
Black metal, nonferrous metal IC thin pieces, surface coating, laminated metal
Description
Microhardness Tester with 100X and 400X Magnification for Ferrous Metals
Low Loading Vickers Micro Hardness Tester

Advanced microhardness testing system with 5 KG capacity and dual magnification capabilities for precise material analysis.

Key Advantages
  • Latest C++ programming for enhanced hardware reliability and stability
  • Unique and precise mechanical, electrical, and optical design
  • 7 testing force levels to meet various measurement requirements
  • Integrated LCD display with manual selection and scales switching functions
  • 10X and 40X objective lenses for observation and measurement
  • Precise locating structure for superior accuracy and reliability
  • High-performance optocoupler control during loading/unloading processes
  • Embedded halogen lamp illumination with 30,000+ hour lifespan
  • Exceptional price-performance ratio
  • Industry-leading advanced technology
Applications

Materials: Black metal, nonferrous metal, IC thin pieces, surface coating, laminated metal

Other Materials: Glass, ceramics, agate, jewels, thin plastic

Specialized Testing: Hardness test for depth and gradient of charring layer and hardening layer

Technical Specifications
Parameter Specification
Testing Force 1.96, 2.94, 4.90, 9.80, 19.6, 29.4, 49.0 N
0.2, 0.3, 0.5, 1.0, 2.0, 3.0, 5.0 Kgf
Carriage Control Full-automatic (loading / holding-up of loading / unloading)
Microscope Magnification 100X, 400X
Holding Time 0-60 seconds
Test Drum Wheel Graduation 0.5μm minimum
Testing Range 5HV - 3999HV
X, Y Stage Dimension 100 × 100 mm
X, Y Stage Travel 25 × 25 mm
Max Specimen Height 200 mm
Max Specimen Width 130 mm
Power Supply 110V/220V, 60/50Hz
Dimensions 550 × 210 × 580 mm
Weight 35 Kg
Standard Accessories
  • Vickers indenter
  • 10X eyepiece
  • Gradienter
  • Cross testing stage
  • Level adjusting screw
  • Vickers hardness block
  • RS232 communication cable
Optional Accessories
  • Knoop indenter
  • Knoop hardness test standard block
  • SP-2008 vision measuring device
  • CCD indentation automatic measuring device
  • Working stage
  • V type working stage
  • Special specimen clamping stage
