Specifications
Brand Name :
FANBAO
Model Number :
BWD4
Certification :
CE
Place of Origin :
chinaPort
MOQ :
1
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
150sets per month
Delivery Time :
5-8 work days
Packaging Details :
standard export wooden case
Product name :
Bwd4 Horizontal Foot Plate Mounted Ordinary Motor Direct Link Cycloidal Pin Gearbox
Output Torque :
2.6-1195N.M
Input Speed :
300-1800Rpm
Output Speed :
14-280rpm
Weight (KG) :
30kg
Ratio :
9-2800
Material :
Steel or cast iron
Gearing Arrangement :
Planetary motor
Port :
Shanghai, Ningbo
Description
BWD XWD1 Cycloidal Pinwheel Reducer Cyclo Planetary Gearbox Motor 380V
Product Specifications
Attribute Value
Gearing Arrangement Planetary motor
Output Torque 2.6-1195N.M
Input Speed 300-1800Rpm
Output Speed 14-280rpm
Weight 30kg
Ratio 9-2800
Material Steel or cast iron
Cycloidal Gear Motor Speed Reducer Overview

The BWD XWD1 cycloid reducer is a precision transmission device that applies planetary transmission principles with cycloid pin tooth meshing. This robust gearbox consists of three main components: input section, reduction section, and output section.

Industrial Reducer Applications

This planetary cycloid reducer is engineered for demanding applications across multiple industries:

  • Power generation equipment
  • Metallurgical processing
  • Petrochemical and mining operations
  • Construction and hoisting machinery
  • Food processing equipment
  • Environmental protection systems
Reducer Features
  • High efficiency: Single stage drive with reduction ratio up to 1:87
  • Compact design: Input and output shafts aligned on same axis
  • Quiet operation: High overlap coefficient cycloid gear reduces noise
  • Durable construction: Bearing steel components for extended service life
Technical Parameters
Parameter Specification
Reducer Stage Number One-stage or two-stage
Housing Material Iron casting
Tooth Surface Hardness HRC58-62
Reducer Installation Type Horizontal or vertical
Bearings NSK, NAK, FAG, HRB
Operational Conditions
  • Designed for continuous operation with bidirectional rotation capability
  • Recommended input speed of 1500 rpm (960 rpm for motors >18.5 kW)
  • Maximum horizontal installation angle of 15°
  • Output shaft not designed for significant axial/radial forces
Quality Assurance

Each reducer undergoes rigorous airtight testing prior to finishing to ensure minimal oil leakage. Our manufacturing process guarantees:

  • High-quality cycloidal wheels made from bearing steel
  • Precision heat treatment for enhanced strength
  • Premium output shafts for reliable performance
  • Extended service life through quality materials
