Orange Button Blue House Silent Tactile Switch 160 ± 50 , 260 ± 50 Gram Force Options
Orange Button Blue House Silent Tactile Switch 160 ± 50 , 260 ± 50 Gram Force Options
Orange Button Blue House Silent Tactile Switch 160 ± 50 , 260 ± 50 Gram Force Options
Orange Button Blue House Silent Tactile Switch 160 ± 50 , 260 ± 50 Gram Force Options
Specifications
Brand Name :
BZCN
Model Number :
TS-F001
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1000 pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000000 pcs per week
Delivery Time :
3 workdays
Packaging Details :
1000 pcs per bag
Material :
PA66
Operation :
Momentary
Current rate :
0.5mA
Button :
orange / white round
Cover :
White plastic
Terminal :
Copper
Description

orange button blue house 12 mm tactile switch 160 ± 50; 260 ± 50 gram force options

Placing the switch such that the direction of
switch operation is vertical and then gradually
increasing the load applied to the center of
the stem, the maximum load required for the
switch to come to a stop shall be measured.

Spec.
Model No. TS-F001
Terminal Type DIP
Switch Rating 50mA DC 12V
Operation Travel 0.2±0.1mm
Operation Tpye Momentary
Operation Force 160/180/250 gf
Operation Life 300,000 Cycles
Contact Resistance ≤100mΩ max
Insulation Resistance ≥100MΩ/m DC 250V
Dielectric Strength AC 250V/m 50Hz
Operation Temperature -30℃ to + 85℃
Operation Humidity 25-85% RH
Solder Ability 260±5℃ for 3 seconds

Reference:

Orange Button Blue House Silent Tactile Switch 160 ± 50 , 260 ± 50 Gram Force Options
