Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
Specifications
Brand Name :
Railteco
Model Number :
RTHZ19
Place of Origin :
China
MOQ :
One pcs
Payment Terms :
L/C, T/T
Supply Ability :
According to customer's requirement
Delivery Time :
4 months after advance payment
Packaging Details :
Railteco Standard Packing
Price :
Negotiable
Name :
Rail Engineering Vehicle Bogie RTHZ19
Axle load :
25t
Tare weight :
≤12t
Diameter of Wheel :
Ø840mm
Journal Center Distance :
1981mm
Max. Running Speed :
40km/h
Description

Railway Bogie RTHZ19 Bogie Wagon Bogie Wheelset Bogie Four Axles Bogie

For Rail Engineering Vehicle Use

Description of Rail Engineering Vehicle Bogie RTHZ19:

This kind of bogie is mainly used in railway engineering vehicles for transporting rails and bridges. The bogie is four-axle welded frame type bogie consisting of a welded frame, two sets of power wheel sets and two sets of non-powered wheel sets, an axle box suspension device, a basic braking device, a lower side bearing device and other ancillary components.

Main Technical Data of Rail Engineering Vehicle Bogie RTHZ19:

Gauge 1435mm
Max. Axle Load 25t
Tare Weight ≤12t
Journal Center Distance 1981mm
Max. Running Speed 40km/h
Diameter of Wheel Ø840mm

Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance

Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance

Multipurpose Four Axles Railway Bogie 1981mm Journal Center Distance
