Specifications
Brand Name :
Ashcroft
Model Number :
1259
Certification :
CO
Place of Origin :
USA
MOQ :
1
Price :
50-300USD
Payment Terms :
T/T
Supply Ability :
99PCS 4-6 WEEKS
Delivery Time :
5-7 WORK DAYS
Mounting Type :
Panel mount
Connection Thread :
M20*1.5,1/2NPT,1/4NPT,G3/8,G1/2,etc
Output Signal :
4-20 mA
Power Supply :
9~36VDC
Range :
0-10kpa....60Mpa
Ingress Protection :
IP65
Pressure Range :
0-100bar-1000bar
Measuring Principle :
Absolute and gauge pressure
Pressure Type :
Gauge pressure
Theory :
pump accessories
Weight :
0.5 kg
Wetted Parts Material :
Stainless Steel
Measuring Medium :
Pressure, Level and Flow
Fill Liquid :
Glycerin
Diaphragm Material :
, Viton, acid, corrosion
Description
1259 Safety Spring Tube Pressure Gauge

The Ashcroft® 1259 is an economical 4.5" ASME process pressure gauge constructed from stainless steel or Monel contact materials, featuring multiple safety enhancements for reliable industrial performance.

Key Features
  • 4.5" dial size for clear visibility
  • ±0.5% full scale accuracy (ASME B40.100 Grade 2A)
  • Multiple damping options including glycerin, silicone oil, and dry seismic resistance
  • Flexible installation options: direct, wall, or panel mounting
  • Pressure relief back cover for enhanced safety
  • CRN and EAC certification approvals
Technical Specifications
Process Connection ¼ NPT, ½ NPT Male (Radial direction)
Liquid Contact Components Bourdon tube: 316L SS, Monel
Process connection: 316L SS, Monel
Non-Liquid Contact Components Shell: PBT polybutylene terephthalate (UL94V-0 compliant)
Cover ring: PBT polybutylene terephthalate (UL94V-0 compliant)
Dial Window Options Ordinary glass, safety glass, acrylic
Pressure Ranges 15-30,000 psi (compound ranges available)
Units Available psi, bar, kg/cm², kPa
Temperature Limits
Dry Gauge -20°F to 250°F (-29°C to 121°C)
PLUS! T Version 20°F to 200°F (7°C to 93°C)
Glycerol Filled -40°F to 200°F (-40°C to 93°C)
Environmental Protection
Dry Gauge Non-enclosed shell, suitable for rainproof environments
Oil Filled IP65 protection rating
Sealed Enclosure IP65 protection rating
Certifications & Approvals: CRN, EAC certified for compliance with industry standards and regulatory requirements.
