Stainless Steel Spring Tube Pressure Gauge Front Baffle Safety Structure
Stainless Steel Spring Tube Pressure Gauge Front Baffle Safety Structure
Stainless Steel Spring Tube Pressure Gauge Front Baffle Safety Structure
Stainless Steel Spring Tube Pressure Gauge Front Baffle Safety Structure
Stainless Steel Spring Tube Pressure Gauge Front Baffle Safety Structure
Stainless Steel Spring Tube Pressure Gauge Front Baffle Safety Structure
Specifications
Brand Name :
Ashcroft
Model Number :
T6500XRA
Certification :
CO
Place of Origin :
USA
MOQ :
1
Price :
20-50USD
Payment Terms :
T/T
Supply Ability :
99PCS 4-6 WEEKS
Delivery Time :
5-7 WORK DAYS
Operating temperature :
-40°C to 85°C
Response time :
≤ 10 ms
Pressure type :
Gauge, Absolute, Differential
Display type :
LCD/LED Digital Display
Measurement range :
0 to 1000 psi
Output signal :
4-20 mA, 0-10 V, Digital
Protection rating :
IP65/IP67
Power supply :
24 V DC
Product name :
Pressure Measurement Instruments
Connection type :
Threaded, Flanged
Mounting options :
Panel, Wall, Pipe
Description
Ashcroft T6500 All Stainless Steel Spring Tube Pressure Gauge
Features front baffle safety structure with high overpressure XRA option for enhanced protection in demanding industrial applications.
Technical Specifications
  • Accuracy: 1% of span for ranges to 60,000 psi; 1.6% of span for ranges >60,000 psi
  • Sizes: 100mm, 160mm
  • Pressure Ranges: 30,000 psi, 40,000 psi, 60,000 psi, 80,000 psi, 100,000 psi
  • Process Connection Location: Lower
  • Process Connection Size: 9⁄16-18UNF-2B right or left handed thread M16 x 1.5 Female
  • Case Style: Stainless steel solid front with full rear blowout back
  • Movement: Adjustable
  • Window Material: Safety glass (standard), polycarbonate (optional)
  • Dial: Aluminum, white background with black figures and intervals
  • Pointer: Aluminum
  • Weather Protection: IP66/67 and NEMA 4X (both dry and liquid filled)
  • Dampening Options: PLUS!™ Performance, glycerin, silicone, or Halocarbon® filled case
  • Mounting: Stem and surface
  • Approvals: CE certified
Wetted Components
Bourdon Tube Process Connection Joints
Inconel 718 316 SS Welded
Non-Wetted Components
Case Ring Back Cover
304 SS (standard)
316 SS (optional)		 304 SS
316 SS		 304 SS
316 SS
Temperature Ranges
Type Ambient Process Storage
Dry -40°F to 158°F (-40°C to 70°C) -40°F to 392°F (-40°C to 200°C) -40°F to 158°F (-40°C to 70°C)
PLUS!™ -40°F to 158°F (-7°C to 70°C) -40°F to 200°F (-40°C to 93°C) -40°F to 158°F (-40°C to 70°C)
Glycerin Fill 19°F to 158°F (-7°C to 70°C) 19°F to 200°F (-7°C to 93°C) -40°F to 158°F (-40°C to 70°C)
Silicone Fill -40°F to 158°F (-7°C to 70°C) -40°F to 200°F (-40°C to 93°C) -40°F to 158°F (-40°C to 70°C)
Halocarbon® Fill -40°F to 158°F (-40°C to 70°C) -40°F to 200°F (-40°C to 93°C) -40°F to 158°F (-40°C to 70°C)
