1379 Duragauge® Safety Type Spring Tube Pressure Gauge a solid-front safety gauge with C-type bourdon tube, 4.5 dial, blowout back, ASME B40.100 compliant.
1379 Duragauge® Safety Type Spring Tube Pressure Gauge a solid-front safety gauge with C-type bourdon tube, 4.5 dial, blowout back, ASME B40.100 compliant.
1379 Duragauge® Safety Type Spring Tube Pressure Gauge a solid-front safety gauge with C-type bourdon tube, 4.5 dial, blowout back, ASME B40.100 compliant.
1379 Duragauge® Safety Type Spring Tube Pressure Gauge a solid-front safety gauge with C-type bourdon tube, 4.5 dial, blowout back, ASME B40.100 compliant.
Specifications
Connection :
1/8 3/8 1/4 1/2"Npt Bsp Bspt and so on
Accuracy Class :
0.2%
Operating Temperature :
-40 to 60 °C
Dial Siza :
60mm,100mm,150mm
Power :
Hydraulic
Feature :
lpg gas pressure gauge manometer
Communication Protocol :
HART
Supply Voltage :
10-30 VDC
Pressure Range :
-100kpa~0~250mpa
Model :
pressure gauge
Brand Name :
Ashcroft
Place of Origin :
USA
MOQ :
1
Supply Ability :
99PCS 4-6 WEEKS
Delivery Time :
5-7 WORK DAYS
Temperature Range :
-40 to 85°C
Customized Support :
OEM
Model Number :
1379
Certification :
CO
Price :
50-250USD
Payment Terms :
T/T
Mounting Type :
Panel Mount
Medium :
high viscosity, strong corrosion
Voltage :
1-5 (V)
Description
1379 Duragauge® Safety Type Spring Tube Pressure Gauge
The Ashcroft® 1379 Duragauge® is a high-performance 4.5" ASME standard process pressure gauge available in dial sizes ranging from 4.5" to 8.5". This safety-type gauge delivers reliable pressure measurement for demanding industrial applications.
Product Specifications
Performance & Construction
  • Accuracy: ±0.5% of span (ASME B40.100, Grade 2A)
  • Sizes: 4½", 6", 8½"
  • Range: Vacuum to 100,000 psi
  • Case Style: Solid front with pressure relief back
  • Movement: Rotary, Adjustable
  • Movement Materials: 400 SS, Teflon® coated pinion gear and segment
  • Window Material: Glass (STD.), Acrylic Window (OPT.), Shatterproof Glass (OPT.)
  • Dial: Aluminum, white background, black pressure scale
  • Pointer: Micrometer Adjustable, Aluminum
Process Connections
  • Location: Lower, Back
  • Size: ¼ NPT Male, ½ NPT Male, 9⁄16-18 UNF-2B (high pressure connection)
Environmental Protection
  • Dry case: Case not sealed, recommended for weather protected environment only
  • Liquid filled or field fillable: IP66 or NEMA 4X
  • Hermetically sealed: IP66
  • Dampening Options: Liquid: glycerin, silicone, Halocarbon®, PLUS!™ Performance
  • Mounting: Stem, Surface, Flush
Wetted Components
Bourdon Tube Process Connection Materials Joints
316L SS 316L SS Welded
316L SS Steel Welded
K-Monel® 500 Tube Monel® 400 Welded
C510 Phos. Bronze Brass Silver brazed
Iconel® 316L SS (60-1379 only) Welded
Non-Wetted Components
  • Case: Aluminum
  • Ring: Polypropylene
  • Back Cover: Polycarbonate
Temperature Limits (°F/°C)
Version Ambient Process Storage
Dry -20°F to 200°F (-29°C to 93°C) -20°F to 250°F (-29°C to 121°C) -40°F to 250°F (-40°C to 121°C)
PLUS!™ -40°F to 150°F (-40°C to 66°C) -40°F to 200°F (-40°C to 93°C) -40°F to 150°F (-40°C to 66°C)
Glycerin fill 20°F to 150°F (-7°C to 66°C) 20°F to 150°F (-7°C to 66°C) 0°F to 150°F (-18°C to 66°C)
Silicone fill -40°F to 150°F (-40°C to 66°C) -40°F to 200°F (-40°C to 93°C) -40°F to 150°F (-40°C to 66°C)
Halocarbon® fill -40°F to 150°F (-40°C to 66°C) -40°F to 200°F (-40°C to 93°C) -40°F to 150°F (-40°C to 66°C)
Approvals
CRN Certified
