Ashcroft 2089 Digital Pressure Gauge a precision digital pressure gauge with backlit LCD, min/max capture, selectable units, and IP65 stainless steel housing.
Ashcroft 2089 Digital Pressure Gauge a precision digital pressure gauge with backlit LCD, min/max capture, selectable units, and IP65 stainless steel housing.
Specifications
Pressure type :
Gauge, Absolute, Differential
Display type :
LCD/LED Digital Display
Payment Terms :
T/T
Delivery Time :
5-7 WORK DAYS
Place of Origin :
USA
Price :
20-30
Response time :
≤ 10 ms
Application :
Industrial Process Control, HVAC, Automotive
Product name :
Pressure Measurement Instruments
Output signal :
4-20 mA, 0-10 V, Digital
Accuracy :
±0.25% of full scale
MOQ :
1
Brand Name :
Ashcroft
Certification :
CO
Measurement range :
0 to 1000 psi
Protection rating :
IP65/IP67
Material :
Stainless Steel
Connection type :
Threaded, Flanged
Mounting options :
Panel, Wall, Pipe
Operating temperature :
-40°C to 85°C
Power supply :
24 V DC
Supply Ability :
99PCS 4-6 WEEKS
Model Number :
2089
Description
Ashcroft 2089 Digital Pressure Gauge
A high-precision testing instrument delivering excellent performance with total full-scale error including linear error, hysteresis, and repeatability error.
Key Features
  • ±0.25% accuracy
  • Weatherproof IP65 enclosure
  • 5-digit LCD display
Accuracy Specifications
  • 2089 Model: ±0.05% of span accuracy
  • 2086 Model: ±0.10% of span accuracy
  • 2084 Model: ±0.25% of span accuracy
Terminal Point, Total Error Band (TEB): Includes hysteresis, linearity, repeatability and temperature (0°F to 150°F)
Physical Specifications
SpecificationDetails
Size3˝
Case Material300 Stainless Steel
Case FinishTumble polished
Process Connection1⁄4 NPT Male
Process Connection LocationLower, left or right
MountingStem
Enclosure RatingWeatherproof, IP65
Display Features
FeatureSpecification
TypeLCD
Display Digits5
Character Height0.66˝
BacklightOff by default, programmable
Bar Graph10 segment
Battery Life1,000 hrs. (3 AAA alkaline batteries)
Pressure Ranges
Gauge, compound, absolute and vacuum through 7,000 psi (see engineering units for other measurement units)
Additional Features
  • Temperature Corrected: Yes
  • Calibration Chart: 10 point traceable calibration chart standard for model 2089 only, optional for models 2084 and 2086
Storage & Protection
  • Stainless steel face cover (included)
  • Zippered gauge pouch (included)
  • Black or orange rubber boot (optional)
  • Weatherproof ABS gauge carrying case (optional)
Material Specifications
ModelNon-Wetted Components
2084, 2086, 2089304 Stainless steel
ModelWetted Components
2084, 2086, 2089316 Stainless steel
Temperature Limits
VersionProcessStorage
2084, 2086, 20890°F to 150°F (–18°C to 65°C)–40°F to 180°F (–40°C to 82°C)
