Specifications
Brand Name :
Limito
Model Number :
LHS201TP-PC08
Place of Origin :
China
Certification :
RoSH, Reach
MOQ :
10pcs
Price :
Negotiable
Packaging Details :
Cartons, Capboard, EPE, Blister Tray.
Delivery Time :
3-5days
Payment Terms :
T/T, Paypal
Supply Ability :
7kk/M
Diagonal Screen Size :
2.01
Drive IC :
ST7789P3
Interface :
8Bit 8080 MCU
Operating Temp :
-20℃~ + 70℃
Storage Temp :
-30℃~+ 80℃
Backlight :
4 White LED Parallel
Brightness :
650
Description

TFT LCD Display 2.01 Inch LCD Module LCD Screen Panel

LIMITO IPS TFT LCD Display Description:

LHS201TP-PC08 is a 240RGBX296 dot-matrix TFT LCD module. This module is composed of a TFT

LCD Panel, driver ICs, FPC and a Backlight unit

LIMITO IPS TFT LCD Display Specification:

LCD Size

2.01

Display Mode

Normally black

Resolution

240(H)RGB x296(V)

Pixel pitch

0.1335(H) x 0.1335(V)

Active area

32.04(H) x 39.516(V)

Module size

34.04(H) x 43.32(M) x1.56 (D)

Pixel arrangement

RGB Vertical stripe

Display Colors

262K

Luminance(cd/m2)

650 (TYP)Cd/m2

Viewing Direction

All View

Weight

3.4g

LIMITO IPS TFT LCD Display Mechanical Drawing

IPS TFT Display 2.01 Inch High Resolution

LIMITO IPS TFT LCD Display Advantages:

Advantages of Customizedized Touch Screen TFT LCD Display (2.01 Inch LCD Module)

  1. Customizedizedizability: The ability to tailor the display size, resolution, and features to specific project requirements ensures optimal performance for different applications.
  2. Touch Functionality: Integrated touch technology enhances user interaction, allowing for intuitive control and navigation within applications.
  3. Compact Size: At 2.01 inches, the display is small and lightweight, making it suitable for handheld devices and wearables.
  4. High Resolution: Offers clear and detailed visuals, improving the overall user experience with sharp images and text.
  5. Vibrant Colors: TFT technology provides bright and accurate color reproduction, enhancing visual appeal in various lighting conditions.
  6. Wide Viewing Angles: Ensures consistent image quality from multiple angles, making it suitable for applications where users may view the screen from different positions.
  7. Low Power Consumption: Designed for energy efficiency, making it ideal for battery-operated devices, extending their operational life.
  8. Robust Durability: Typically built to withstand environmental stresses, ensuring reliability in various settings, including industrial and outdoor applications.
  9. Versatile Applications: Suitable for a range of uses, including consumer electronics, medical devices, and industrial control panels.
  10. Easy Integration: Compatible with various microcontrollers and development boards, simplifying the design and implementation process.
