Specifications
Brand Name :
MacweyTEK
Model Number :
MKZX(F)9-10
Certification :
IEC
Place of Origin :
China
MOQ :
3
Price :
$199
Payment Terms :
T/T
Supply Ability :
10000 pcs
Delivery Time :
18 days
Packaging Details :
wooden case
Name :
CT PT Transformer
Rated Voltage :
10kV
Model :
MKZX(F)9-10
Accuracy Class :
0.2
Application :
Voltage Measurement & Monitoring, Power Supply for Voltmeters & Relays
Core Feature :
Small Capacity, Small Voltage/Current Variation Difference
Description
MKZX(F)9-10 10kV Potential Transformer PT VT Voltage Transformer

The transformer is one of import electrical appliances in electric system. It's similar to power transformer and also used to transformer voltage or current in the circuit. However, transforming voltage and current by power transformer aims at transferring electric energy while transforming voltage and current by transformer aims at measuring and monitoring voltage or current in the circuit. Generally, power transformer owns large capacity as well as large change difference of voltage or current. While transformer owns small capacity as well as smaller change difference of voltage or current. In measuring circuit. The transformer that transforms current and supplies electricity for current meter and relay is called current transformer. The transformer that transforms voltage and supplies electricity for voltage meter and relay is called voltage transformer.


Type Rated voltage ratio(kV) Accuracy class and rated output (VA) Max output (VA) Rated insulation level (kV)
0.2 0.5 1 6P
MKZXF9-10 10/√3/0.1/√3/0.1/√3/0.1/3 20 20 50 100 2*300 12/42/75
MKZXF9-6 6/√3/0.1/√3/0.1/√3/0.1/3 7.2/32/60
MKZXF9-3 3/√3/0.1/√3/0.1/√3/0.1/3 3.6/25/40
MKZXF9-10 10/√3/0.1/√3/0.1/√3 25 90 180 100 500 12/24/75
MKZXF9-6 6/√3/0.1/√3/0.1/√3 7.2/32/60
