6.2kW Grid Tie Inverter High Conversion Efficiency 6200W Grid Connected Inverter
6.2kW Grid Tie Inverter High Conversion Efficiency 6200W Grid Connected Inverter
Specifications
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
$300-$500
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Input Frequency  :
50/60Hz±5%
LCD Interface :
can display operating mode/load/input/output
Description
6.2kW Grid-Tie Solar Inverter
Wide PV Input Voltage & High Conversion Efficiency for Home Energy Storage
Product Highlights
  • Wide PV Input Voltage Range: Supports 60-500V input, compatible with various solar panels and delivering strong application adaptability
  • External WiFi Module: Equipped with external WiFi interface for remote device monitoring and control
  • High Conversion Efficiency: High energy conversion efficiency with low power consumption loss, enhancing overall system performance
  • Multiple Battery Type Compatibility: Flexible configuration options for energy storage systems
  • Sturdy & Compact Structure: Lightweight yet durable casing design for easy installation and space saving
Application Scenarios
  • Small household photovoltaic systems for on-site self-consumption and surplus power storage
  • Remote areas with limited grid access, providing stable power for household appliances and lighting
  • Emergency backup power supply for households and small stores during power outages
Additional Advantages
  • Factory Direct Supply: Own production base with direct order handling for stable and efficient supply
  • Flexible Production: Support for small-batch trial orders with minimum order quantity of 1 unit
  • Customization Service: Customizable specifications including voltage, interfaces and other parameters
6.2kW Grid Tie Inverter High Conversion Efficiency 6200W Grid Connected Inverter
Technical Specifications
Model: CH-ED6248EMH
AC Input
AC Input Voltage 220VAC (Normal) / 110VAC (Customize)
Input Voltage Range 90-280VAC±3V (Normal Mode)
170-280VAC±3V (UPS Mode)
Input Frequency 50/60Hz±5%
Rated Power 6200W
Output
Rated Power 6200W
Output Voltage 220/230/240VAC±5%
Output Frequency 50/60Hz±0.1%
Output Wave Pure Sine Wave
Transfer Time ≤10ms (UPS) / ≤20ms (INV)
Peak Power 12400VA
Overload Ability Battery Mode: 1s@105%-150% Load
2s@150%-200% Load
400ms@200% Load
Grid-connected Operation
Output Voltage 220/230/240VAC
Grid Voltage Range 170-265VAC
Grid Frequency Range 49-51±Hz / 59-61±Hz
Rated Output Current 26.9A
Power Factor Range >0.99
Peak Efficiency (DC/AC) 98%
Battery
Rated Voltage 48Vdc
Configurable Voltage 56.4Vdc
Charging Voltage (Configurable) 54Vdc
Charger
PV Charging Mode MPPT
Max PV Input Power 6200W
MPPT Input Voltage Range 60-500Vdc
Optimal Vmp Range 400-400Vdc
Max PV Input Voltage 500Vdc
Max PV Input Current 18A
Max PV Charging Current 120A
Max AC Charging Current 100A
Max Charging Current 120A
Display & Interface
LCD Interface Displays operating mode, load, input/output
RS232 Baud Rate 2400
Expansion Slot Communication Interface Lithium Battery BMS Communication Card, WIFI/Pitch 2.54mm
Support Parallel Not supported
Environmental Specifications
Operating Temperature -10°C to 50°C
Operating Environment Humidity -10°C to 60°C
Storage Temperature 20%-90% Non-Condensing
Noise ≤50dB
