15 DBi 2.4 GHz Long Distance Base Station Antennas Wifi Directional Panel
15 DBi 2.4 GHz Long Distance Base Station Antennas Wifi Directional Panel
15 DBi 2.4 GHz Long Distance Base Station Antennas Wifi Directional Panel
15 DBi 2.4 GHz Long Distance Base Station Antennas Wifi Directional Panel
Specifications
Place of Origin :
Shenzhen China
Brand Name :
Runshine
Certification :
ROSH
Model Number :
RSP-2400-15
MOQ :
100pcs
Delivery Time :
1 week after received the payment
Payment Terms :
TT in advance
Type :
Base Station Antenna
Feature :
High Gain,H or V Polarization
Pole diamete(mm) :
50～75
Rated Wind Velocit(m/s) :
60
Application :
Public wireless hot signal coverage/2.4GHz ISM
Beamwidth(0°) :
H:120 V:7
Description

15 DBi 2.4 GHz Long Distance Base Station Antennas Wifi Directional Panel

Feature:


● High Gain
● H or V Polarization
● Full day for working
● Durable, corrosion resistance
● Optimized dimension

Application:


● 2.4 GHz WIFI WLAN System
● 2.4GHz ISM applications
● Public wireless hot signal coverage
● Base station &Repeater station system

Specifications

RSP-2400-15

Electric Specifications

Frequency rang

2400-2500

Polarization

Vertical

Gain(DBi)

15

Beamwidth(0°)

H:120 V:7

F/B ratio(DB)

≥25

Input Impedance(Ω)

50

VSWR

≤1.5

Max power(W)

200

Mechanical Specifications

Connector model

N Female

antenna size (mm)

1210*114*54

Packing size(mm)

1240*125*105

Antenna weight (kg)

6.5

Radome material

UPVC

Radome color

Gray

Mechanical tilt(°)

0～10

Working Temperature(°c)

-40～60

Rated Wind Velocity(m/s)

60

Pole diameter(mm)

50～75

Antenna details :

Application Example :

Install demonstration

View of us ;
