Specifications
Brand Name :
Dimax
Model Number :
150 non thermal break series French Door
Certification :
AS 2047
Place of Origin :
China
MOQ :
1
Price :
800-1200rmb
Payment Terms :
L/C,T/T
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Surface treatment :
Anodized,Powder Coating,Powder Coated,Anodized/Powder coating/Electrophoresis /PVDF,PVDF
Description

INFORMATION

System Swing door(French door)
Brand DIMAX
Material 6063-T5
Certification AS2047
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux and so on(warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,Doric and so on
Configuration Single door,double door,door with sidelight
Flyscreen Fiberglass/Stainless steel available
Fixing Method Sub sill/Sub head/Finx fix/Face fix/Timber reveal available
Air Infiltration 75pa
Design Wind Pressure 970pa
Water Resistance 291Pa
Ufimate Wind Pressure 1500pa
Operating Force Test -
Insulative Effectiveness Configure according to the project requirements
soundlnsulafion Configure according to the project requirements

We deeply understand how a door defines the character of a space and the way it connects. The 150 Series Non-Thermal Break French Door System is designed for residential and commercial environments that prioritize expansive views, structural stability, and long-term durability. This series utilizes high-specification extruded aluminum, whose material density and cross-sectional thickness significantly exceed those of standard roll-formed aluminum profiles, ensuring the door’s core advantages in resistance to deformation and corrosion from the outset. The non-thermal break structure excels in temperate and mild climate zones, maintaining the full strength transmission of the aluminum while avoiding unnecessary thermal bridging effects—making it an ideal balance of performance and cost.

The series emphasizes detail and practical experience: reinforced frames and beam supports ensure the safety and stability of large-area glass panels; multiple sealing layers effectively control air infiltration and rainwater ingress; surface treatments offer various coating processes to adapt to different architectural styles; opening methods support single-leaf, double-leaf, and symmetrical combined designs to meet diverse scenario needs. We also provide flexible services ranging from standard sizes to fully customized solutions, covering glass configurations, hardware accessories, and technical installation support to ensure every door perfectly integrates with its architectural space.

Choosing the 150 Series Non-Thermal Break French Door means not only selecting a door but also embracing time-tested material science, bright and open spatial interaction, and a sustainable architectural philosophy of low maintenance and long lifespan.
