Classic Hinged Casement Aluminium Window Weather Proof Customization
Classic Hinged Casement Aluminium Window Weather Proof Customization
Specifications
Brand Name :
Dimax
Model Number :
108 series Casemen window
Certification :
ISO9001,OHSAS18001,ISO 9001,CE,Qualanod
Place of Origin :
China
MOQ :
1
Price :
1000-1200rmb
Payment Terms :
L/C,T/T
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Type :
Curtain Walls,100% QC Testing,Exposed Frame,Float Glass
Function :
Heat-insulation,Mould-Proof Waterproof Antibacterial Fireproof Anti-Static,Waterproof,Fireproof,Soundproof
Hardware :
China Top Brand,CHINA BRAND OR GERMAN,High Quality Made in China,Chinese brand or International brand for 10 years warraty,ALUK brand
Shape :
Customized.,hexagonal,Square,honeycomb
Glass color :
Blue,TINT GLASS OR REFLECTIVE,Grey,Green,Grey/Green/Blue/Tea/or the others or clear
Warranty :
20 Years,GB5237-2008 equal to EN12020-1.2(2001),1 year,7 years
Frame :
6063-T5 grade of aluminum alloy,Invisible Frame Glass Curtain Wall,STANDARD ALUMINUM PROFILE
Description

108 Series Casement Window: Classic Hinged Design with Enhanced Ventilation Control & Weather Resistance

INFORMATION

Brand Dimax
Material 6063-T5
Thickness 2.0mm
Bearing 80kg
Blade width 600-900mm
Blade height 600-1900mm
Certification NFRC, CSA, CE,
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux (warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,ROTO and so on
Configuration A. AA. A/F or customized design
Heat Insulation UW1.12W/㎡K
soundlnsulafion Rw up to 37dB
Ufimate Wind Pressure +5040pa
Water Resistance +720Pa

The 108 Series Casement Window features a reinforced multi-point locking system and a triple-layer sealing structure, delivering excellent airtightness and wind pressure resistance suitable for high-rise buildings and coastal windy environments. The sash can open outward up to 90 degrees or tilt inward by 15 degrees, combined with a removable screen design for balanced ventilation control and easy cleaning. The profile utilizes multi-chamber thermal break aluminum with injection foam technology, paired with low-emissivity insulating glass to achieve a thermal transfer coefficient as low as 1.5 W/(m²·K), meeting passive building energy standards. Surface finishes include anodizing, powder coating, and wood grain transfer, with personalized color customization available. Ideal for residential, office, educational, and healthcare projects that demand high safety, energy efficiency, and aesthetic standards.
