Vertical Side Hung Aluminium Windows For Optimized Ventilation And Space Efficiency
Vertical Side Hung Aluminium Windows For Optimized Ventilation And Space Efficiency
Specifications
Brand Name :
Dimax
Model Number :
140 series Hung window
Certification :
ISO9001,OHSAS18001,ISO 9001,CE,Qualanod
Place of Origin :
China
MOQ :
1
Price :
1000-1200rmb
Payment Terms :
L/C,T/T
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Usage :
Exterior Facade Curtain Wall,Exterior Tiles,Outdoor Indoor
Name :
guangzhou building material price glass aluminum curtain wall,Laminated Glass Curtain Wall Prices,Insulated Aluminium Curtain Wall,Aluminum Frame Glass Curtain Wall Profile,China factory price energy efficient insulated glass curtain wall
Function :
Heat-insulation,Mould-Proof Waterproof Antibacterial Fireproof Anti-Static,Waterproof,Fireproof,Soundproof
Hardware :
China Top Brand,CHINA BRAND OR GERMAN,High Quality Made in China,Chinese brand or International brand for 10 years warraty,ALUK brand
Shape :
Customized.,hexagonal,Square,honeycomb
Glass color :
Blue,TINT GLASS OR REFLECTIVE,Grey,Green,Grey/Green/Blue/Tea/or the others or clear
Warranty :
20 Years,GB5237-2008 equal to EN12020-1.2(2001),1 year,7 years
Description

140 Series Hung Window: Vertical-Slide Design for Optimized Ventilation & Space Efficiency

INFORMATION

Brand Dimax
Material 6063-T5
Thickness 3.0mm
Bearing 30kg
Blade width 600-1200mm
Blade height 600-1900mm
Certification NFRC, CSA, CE,
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux (warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,ROTO and so on
Configuration A. AA. A/F or customized design
Heat Insulation UW1.7W/㎡K
soundlnsulafion Rw up to 35dB
Ufimate Wind Pressure +2000pa
Water Resistance +330Pa

The 140 Series Hung Window employs a vertical sliding structure equipped with a self-balancing counterweight system and low-friction rollers, enabling independent opening and closing within a single sash frame and allowing the window to remain securely suspended at any position. The frame is constructed from multi-chamber thermally broken aluminum profiles, combined with triple-glazed insulating glass and warm-edge spacer bars, achieving a whole-window thermal transfer coefficient as low as 1.3 W/(m²·K) to enhance building energy efficiency. The system comes standard with concealed wind-resistant locks and removable screens, featuring a dual-sided cleaning design to meet both high-rise safety regulations and ease of daily maintenance. Options include manual cranks, chain drives, or motorized smart controls, making it suitable for residential, educational, healthcare, and other building environments with stringent requirements for ventilation control, energy efficiency, and operational safety.
