Flexible Lateral Swing Side Hung Aluminium Windows For Enhanced Ventilation Easy Maintenance
Flexible Lateral Swing Side Hung Aluminium Windows For Enhanced Ventilation Easy Maintenance
Specifications
Brand Name :
Dimax
Model Number :
100side-hinged window
Certification :
AS 2047
Place of Origin :
China
MOQ :
1
Price :
1000-1200
Payment Terms :
L/C,T/T
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Type :
Curtain Walls,100% QC Testing,Exposed Frame,Float Glass
Name :
guangzhou building material price glass aluminum curtain wall,Laminated Glass Curtain Wall Prices,Insulated Aluminium Curtain Wall,Aluminum Frame Glass Curtain Wall Profile,China factory price energy efficient insulated glass curtain wall
Function :
Heat-insulation,Mould-Proof Waterproof Antibacterial Fireproof Anti-Static,Waterproof,Fireproof,Soundproof
Hardware :
China Top Brand,CHINA BRAND OR GERMAN,High Quality Made in China,Chinese brand or International brand for 10 years warraty,ALUK brand
Shape :
Customized.,hexagonal,Square,honeycomb
Glass color :
Blue,TINT GLASS OR REFLECTIVE,Grey,Green,Grey/Green/Blue/Tea/or the others or clear
Warranty :
20 Years,GB5237-2008 equal to EN12020-1.2(2001),1 year,7 years
Frame :
6063-T5 grade of aluminum alloy,Invisible Frame Glass Curtain Wall,STANDARD ALUMINUM PROFILE
Description

100 Series Side-Hinged Window: Flexible Lateral Swing for Enhanced Ventilation & Easy Maintenance

INFORMATION

Brand Dimax
Material 6063-T5
Thickness 2.0mm
Bearing 60kg
Blade width 600-800mm
Blade height 600-1600mm
Certification NFRC, CSA, CE,
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux (warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,ROTO and so on
Configuration A. AA. A/F or customized design
Heat Insulation UW1.5W/㎡K
soundlnsulafion Rw up to 37dB
Ufimate Wind Pressure +3000pa
Water Resistance +720Pa

The 100 Series Side-Hinged Window utilizes a side-pivot rotating structure, allowing the sash to open horizontally up to 180 degrees and remain securely positioned at any angle, facilitating two-sided cleaning and serving as an emergency escape passage when needed. The frame is equipped with reinforced stainless steel hinge load-bearing systems and multi-point interlocking locks, combined with a triple-compression sealing design, achieving the highest national standard of Level 9 wind pressure resistance. The profiles feature wide-chamber thermally broken aluminum with injected thermal barrier technology, paired with adjustable ventilators and Low-E insulating glass, resulting in a whole-window thermal transfer coefficient as low as 1.4 W/(m²·K). Optional accessories include concealed stainless steel mesh screens, motorized opening/closing mechanisms, and rain-sensing smart modules, making it suitable for hospitals, schools, hotels, and renovation projects in older buildings where integrated demands for ventilation efficiency, safety protection, and energy performance are critical.
