Smooth Multiglide Sliding Glass Doors For Modern Indoor Outdoor Transitions
Smooth Multiglide Sliding Glass Doors For Modern Indoor Outdoor Transitions
Specifications
Brand Name :
Dimax
Model Number :
125 series Sliding Door
Certification :
AS 2047
Place of Origin :
China
MOQ :
1
Price :
1000-1200rmb
Payment Terms :
L/C,T/T
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Profile Structure :
High-Strength Narrow-Frame Aluminum Alloy
Roller System :
Low-Friction Load-Bearing Roller Group
Glass Configuration :
Double-Glazed Laminated Insulating Glass (Triple-Glazed / Low-E Coating Optional);
Wind Pressure Resistance :
Complies with GB/T 7106-2019 Level 9 Standard
Description

125 Series Sliding Door: Smooth Wide-Panel Glide for Modern Indoor-Outdoor Transitions

INFORMATION

Brand Dimax
Material 6063-T5
Thickness 3.0mm
Bearing 300kg
Blade width 600-2500mm
Blade height 1500-3500mm
Certification NFRC, CSA, CE,
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux (warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,ROTO and so on
Configuration XXO,OXX,OXXXXO,corner slider or customized design
Heat Insulation UW1.7W/㎡K
soundlnsulafion Rw up to 37dB
Ufimate Wind Pressure +2160pa
Water Resistance +330Pa

The 125 Series Sliding Door employs high-strength narrow-frame aluminum profiles paired with a low-friction roller system, enabling smooth and quiet operation of wide-span door panels tailored for open-space designs in modern architecture. The system comes standard with double-glazed laminated insulating glass, effectively reducing external noise while enhancing safety and impact resistance, and supports customized single-panel dimensions up to 1800mm × 2400mm. The track features an innovative embedded self-cleaning design, combined with multi-point locking and anti-lift mechanisms at the base to ensure long-term structural stability in coastal and windy environments. An optional smart electric control system is available, supporting remote control, sensor activation, and integration with security devices—delivering a technologically advanced access solution for high-end residences, commercial galleries, and hospitality spaces.
