Seamless Sliding Aluminium Window Heat Insulation Aluminium Sliding Patio Doors
Seamless Sliding Aluminium Window Heat Insulation Aluminium Sliding Patio Doors
Specifications
Brand Name :
Dimax
Model Number :
150 series Sliding Door
Certification :
ISO9001,OHSAS18001,ISO 9001,CE,Qualanod
Place of Origin :
China
MOQ :
1
Price :
1000-1200rmb
Payment Terms :
L/C,T/T
Supply Ability :
6000 square meters/month
Delivery Time :
45
Packaging Details :
Dimax standard
Name :
guangzhou building material price glass aluminum curtain wall,Laminated Glass Curtain Wall Prices,Insulated Aluminium Curtain Wall,Aluminum Frame Glass Curtain Wall Profile,China factory price energy efficient insulated glass curtain wall
Function :
Heat-insulation,Mould-Proof Waterproof Antibacterial Fireproof Anti-Static,Waterproof,Fireproof,Soundproof
Hardware :
China Top Brand,CHINA BRAND OR GERMAN,High Quality Made in China,Chinese brand or International brand for 10 years warraty,ALUK brand
Shape :
Customized.,hexagonal,Square,honeycomb
Glass color :
Blue,TINT GLASS OR REFLECTIVE,Grey,Green,Grey/Green/Blue/Tea/or the others or clear
Warranty :
20 Years,GB5237-2008 equal to EN12020-1.2(2001),1 year,7 years
Frame :
6063-T5 grade of aluminum alloy,Invisible Frame Glass Curtain Wall,STANDARD ALUMINUM PROFILE
Description

150 Series Sliding Door: Wide-Aperture Gliding System for Seamless Indoor-Outdoor Integration

INFORMATION

Brand Dimax
Material 6063-T5
Thickness 2.0mm
Bearing 300kg
Blade width 600-3000mm
Blade height 1500-3500mm
Certification NFRC, CSA, CE,
Glass Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass
Powder-coat Interpon, Dulux (warranty treatment 10/20 years)
Hardware KIN LONG,BONWAY,ROTO and so on
Configuration XXO,OXX,OXXXXO,corner slider or customized design
Heat Insulation UW1.7W/㎡K
soundlnsulafion Rw up to 35dB
Ufimate Wind Pressure +3600pa
Water Resistance +720Pa

The 150 Series Sliding Door features a heavy-duty dual-track load-bearing structure equipped with precision-machined stainless steel roller systems, ensuring quiet and smooth movement even under long-term high-frequency use. Its narrow-frame design combined with ultra-clear tempered insulated glass provides up to 92% visible light transmittance, enabling seamless integration between architectural facades and natural landscapes. The system includes triple-layer compression seals and bottom brush-type wind barriers as standard, maintaining exceptional air and water tightness even in coastal and high-wind environments. It supports flexible configurations such as single-track double-panel, dual-track four-panel, and asymmetric layouts, with optional concealed floor tracks and intelligent motorized drive modules—ideal for wide-span openings in hotel lobbies, commercial spaces, and premium residential projects.
