Custom 16CH PMFA Block (12x3.5x2mm) | Slow Axis Aligned FC/APC | PM1550 with 2m Blue Tube | Coherent Optical Component
Custom 16CH PMFA Block (12x3.5x2mm) | Slow Axis Aligned FC/APC | PM1550 with 2m Blue Tube | Coherent Optical Component
Custom 16CH PMFA Block (12x3.5x2mm) | Slow Axis Aligned FC/APC | PM1550 with 2m Blue Tube | Coherent Optical Component
Custom 16CH PMFA Block (12x3.5x2mm) | Slow Axis Aligned FC/APC | PM1550 with 2m Blue Tube | Coherent Optical Component
Specifications
Channel count :
16
Channel spacing :
127μm
Insertion loss :
≤0.3dB
Extinction ratio :
≥18dB
Description
Custom 16CH PMFA Block (12x3.5x2mm) | Slow Axis Aligned FC/APC | PM1550 with 2m Blue Tube | Coherent Optical Component
1. Product Overview

The 16CH PMFA polarization-maintaining fiber array uses Corning PM1550 polarization-maintaining fiber with a channel spacing of 127μm, 0° end-face polishing, FC/APC connectors, slow axis alignment with the key, and is equipped with 0.9mm blue loose tubes. The length including the connector is 200±10cm.

2. Core Product Features
Parameters Unit Spec. Value
Channel / 24 OK
Material / Quartz Glass OK
Channel Spacing μm 127 OK
Polishing Angle Degree 0° OK
Package(L)X(W)X(H) mm 12*5.7*1.5 OK
Insertion Loss dB ≤0.3
Extinction Ratio dB ≥18 25
FA PM Fiber Alignment / PMII OK
Connctor PM Fiber Alignment / Slow Axis
Alignment Key		 OK
Fiber Type / PM1550(Corning) OK
Fiber Tube mm 0.9 OK
Tube Color / Blue OK
Length m 1±0.1 OK
Connector / FC/APC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK


  • 16-channel polarization-maintaining fiber array design
  • 127μm high-precision channel spacing
  • 0° end-face polished structure
  • Insertion loss IL < 0.3dB
  • Extinction ratio ER > 18dB
  • Uses Corning PM1550 polarization-maintaining fiber
  • FC/APC connector, slow axis alignment key
  • FA size 12*3.5*2mm, compact structure
3. Applications
  • Silicon photonics chip and PIC coupling packaging
  • Polarization-maintaining optical devices and optical module packaging
  • Coherent communication systems
  • Fiber optic sensing and interferometric testing systems
  • Coupling of lasers, modulators, and integrated devices
  • Polarization-sensitive optical experimental and testing platforms
  • High-density multi-channel optical interconnect systems
