PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array
PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array
PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array
PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array
PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array
PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array
Specifications
Brand Name :
Gracyfiber
Certification :
ISO9001 , ROHS
Place of Origin :
Guangdong , China
MOQ :
100pcs
Payment Terms :
L/C,T/T
Delivery Time :
5-8 work days
Supply Ability :
100,000 pieces per month
V-groove pitch :
127/250/500(±0.5)μm or custom
Polishing angle :
90°(±0.3°)
Extinction ratio :
≥15-25 dB (channel-dependent)
Fiber length :
1±0.1m
Operating temperature :
-5 to 65℃
Storage temperature :
-40 to 85℃
Name :
Fiber Array Unit
Description

PM SM Hybrid Fiber Array Polarization Maintaining Single Mode V Groove Fiber Array For Coherent Optical Transceiver Module

1. Product Overview

High-quality PM+SM hybrid fiber arrays integrate polarization-maintaining fiber (PM) and single-mode fiber (SM) into a single array to meet specific customer application requirements.



PM SM Hybrid Fiber Array Unit Polarization Maintaining Single Mode V Groove Fiber Array

Key Features:

Arbitrary Combinations

High Precision

High Extinction Ratio

Diverse Specifications:


2. Product Features (Key Features)

Material

Quartz& Silicon

V-groove core pitch

μm

127/250/500(±0.5)or customer specified

wavelength


460 780 980 1060 1310

Polishing angle

degree

90°(±0.3°)

Number of channels

1

2

4

8

16

32

64

Channel spacing

μm

　

250

127

127

127

127

127

Package
(L)X(W)X(H)

mm

6x2.5x2.5

10x2.5x2.5

10x2.5x2.5

10x2.5x2.5

12x3.5x2.5

12x5.7x2.5

12X9.7X2.5

Extinction ratio

dB

≥25

≥25

≥23

≥21

≥20

≥16

≥15

PM Fiber Alignment

PM orientation Ⅱ

Fiber Type

Corning PM15-U25D

Fiber Length

1+/-0.1m

Connector

FC/APC(Slow Axis Alignment Key)

Operating Temperature (℃)

-5～65

Storage Temperature (℃)

-40～85
3. Applications


Optical Devices/Modules

Coherent Optical Transceivers
