Specifications
Model Number :
910001716-16
Channel Count :
16
Channel Spacing :
127 μm
Polishing Angle :
8°
Extinction Ratio :
25 dB
Description
16CH PM Fiber Array | 127μm Pitch, 8° Quartz Block | PM1550 Fiber, Slow Axis to Key | High ER 25dB PMFA | Gracyfiber
1. Product Overview

This product is a 16-channel polarization-maintaining fiber array (PMFA), using quartz glass and Corning PM1550 polarization-maintaining fiber. The channel spacing is 127 μm, and the polishing angle is A8°.

2. Core Product Features

Parameters Unit Spec. Value
Channel / 24 OK
Material / Quartz Glass OK
Channel Spacing μm 127 OK
Polishing Angle Degree 0° OK
Package(L)X(W)X(H) mm 12*5.7*1.5 OK
Insertion Loss dB ≤0.3
Extinction Ratio dB ≥18 25
FA PM Fiber Alignment / PMII OK
Connctor PM Fiber Alignment / Slow Axis
Alignment Key		 OK
Fiber Type / PM1550(Corning) OK
Fiber Tube mm 0.9 OK
Tube Color / Blue OK
Length m 1±0.1 OK
Connector / FC/APC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK
  • 16-channel high-density array design
  • A8° polished end face
  • Low insertion loss performance
  • Excellent polarization-maintaining performance
    ER > 18 dB
  • Compact structure, easy to integrate
3. Applications
  • 1550 nm polarization-maintaining fiber communication systems
  • Coherent optical communication modules
  • Multi-channel optical modules and transceiver packaging
  • Silicon photonics chip coupling and photonic integration packaging
  • Fiber optic sensing, interferometers, and polarization control systems
  • Laboratory optical path coupling, testing platforms, and precision optical equipment
