4CH PM Fiber Array, Borofloat 33 Fiber Array, PM1310 Fiber Array, Polarization Maintaining FA
4CH PM Fiber Array, Borofloat 33 Fiber Array, PM1310 Fiber Array, Polarization Maintaining FA
4CH PM Fiber Array, Borofloat 33 Fiber Array, PM1310 Fiber Array, Polarization Maintaining FA
4CH PM Fiber Array, Borofloat 33 Fiber Array, PM1310 Fiber Array, Polarization Maintaining FA
Specifications
Model Number :
910001704-03-1
Channel count :
4
Channel spacing :
127μm
Polishing angle :
A15°
Insertion loss :
≤0.3dB
Extinction ratio :
≥18dB
Description
4CH PM Fiber Array, Borofloat 33 Fiber Array, PM1310 Fiber Array, Polarization Maintaining FA
1. Product Overview

The 4CH PMFA polarization-maintaining fiber array uses PM1310 Corning polarization-maintaining fiber, with a channel spacing of 127μm, a polishing angle of A15°, and is equipped with FC/APC connectors and 0.9mm red loose tubes.

2. Core Product Features

Parameters Unit Spec. Value
Channel / 24 OK
Material / Quartz Glass OK
Channel Spacing μm 127 OK
Polishing Angle Degree 0° OK
Package(L)X(W)X(H) mm 12*5.7*1.5 OK
Insertion Loss dB ≤0.3
Extinction Ratio dB ≥18 25
FA PM Fiber Alignment / PMII OK
Connctor PM Fiber Alignment / Slow Axis
Alignment Key		 OK
Fiber Type / PM1550(Corning) OK
Fiber Tube mm 0.9 OK
Tube Color / Blue OK
Length m 1±0.1 OK
Connector / FC/APC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK

  • 4-channel polarization-maintaining fiber array design
  • 127μm high-precision channel spacing
  • A15° angled polishing structure
  • Insertion loss IL≤0.3dB
  • Extinction ratio ER≥18dB, measured up to 25dB
  • Uses PM1310 Corning polarization-maintaining fiber
  • FC/APC connector, slow axis alignment key
  • V-groove size 10*1*1.5mm, compact structure
3. Applications
  • Silicon photonics chip coupling
  • Polarization-maintaining optical module and optical device packaging
  • Coherent communication systems
  • Fiber optic sensing systems
  • Polarization-sensitive optical testing systems
  • Laser, modulator, and integrated optical path coupling
  • High-precision multi-channel optical coupling components
