High ER 8-Channel Polarization Maintaining FA | PM630-HP Fiber, 127μm Spacing, 8 Degree APC | Quartz Glass PMFA | Low IL
High ER 8-Channel Polarization Maintaining FA | PM630-HP Fiber, 127μm Spacing, 8 Degree APC | Quartz Glass PMFA | Low IL
High ER 8-Channel Polarization Maintaining FA | PM630-HP Fiber, 127μm Spacing, 8 Degree APC | Quartz Glass PMFA | Low IL
High ER 8-Channel Polarization Maintaining FA | PM630-HP Fiber, 127μm Spacing, 8 Degree APC | Quartz Glass PMFA | Low IL
Specifications
Channel count :
8
Channel spacing :
127μm
Polishing angle :
8°
Extinction ratio :
≥18dB
Description
Product Overview

The 8CH PMFA polarization-maintaining fiber array utilizes a Quartz Glass substrate and Corning PM630-HP polarization-maintaining fiber, featuring an A8° polishing angle, 127μm channel pitch, and FC/APC connectors.

Features
Parameters Unit Spec. Value
Channel / 8 OK
Material / Quartz Glass OK
Channel Spacing μm 127 OK
Polishing Angle Degree A8° OK
Package(L)X(W)X(H) mm 10*2.5*2.5 OK
Connector / FC/APC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK
  • 8-channel PMFA polarization-maintaining fiber array
  • Quartz Glass substrate
  • 127μm channel pitch
  • A8° polishing angle
High ER 8-Channel Polarization Maintaining FA | PM630-HP Fiber, 127μm Spacing, 8 Degree APC | Quartz Glass PMFA | Low IL <0.3dB
Applications
  • Polarization-maintaining optical chip input/output coupling
  • Polarization-sensitive optical communication modules
  • Silicon photonics device testing and packaging
  • Coherent optical communication systems
  • Fiber optic sensing systems
  • Laser coupling components
  • Polarization control optical path systems
  • Precision optical testing platforms
  • Multi-channel polarization-maintaining passive devices
  • Laboratory R&D and customized optical path integration
