1CH SM Fiber Array | 0° Flat Polish, Quartz Block 2.5x2.5x7.9mm | Corning SMF-28e, FC/PC | Low IL <0.3dB, High RL >55dB

1. Product Overview

This product is a 1-channel single-mode fiber array (SMFA), using quartz glass and Corning SMF-28e single-mode fiber, with a polishing angle of A0°.

2. Core Product Features
Parameters Unit Spec. Value
Channel / 1 OK
Material / Quartz Glass OK
Channel Spacing μm
OK
Polishing Angle Degree 0° OK
Package(L)X(W)X(H) mm 2.5*2.5*7.9 OK
Insertion Loss dB ≤0.3 　
Extinction Ratio dB ≥18 25
FA PM Fiber Alignment /
OK
Connctor PM Fiber Alignment /
OK
Fiber Type / SMF-28e OK
Fiber Tube mm 0.9 OK
Tube Color / White OK
Length m 1±0.1 OK
Connector / FC/PC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK

Single-channel single-mode fiber array design
Adopting a 1CH structure, it is suitable for precise coupling, transmission, and optical device packaging applications of single-path optical signals.

Low insertion loss performance
Insertion loss IL < 0.3 dB, effectively reducing optical link loss and improving optical signal transmission efficiency.

High return loss performance
Return loss RL > 55 dB, helping to reduce end-face reflections and improve system transmission stability.

Compact FA structure
Using Quartz Glass, the FA size is 2.5 * 2.5 * 7.9 mm, with a compact structure that facilitates integration into compact optical devices.

Comprehensive connectivity and protection configuration
Equipped with Corning SMF-28e single-mode fiber and FC/PC connectors, with a length of 100 ± 10 cm including the connector, and an external 0.9 mm white loose tube for easy installation, testing, and system connection.

3. Applications
  • Single-mode fiber optic communication systems
  • Optical module and optical device packaging
  • Optical path coupling for lasers, modulators, and detectors
  • Silicon photonic chip coupling and photonic integrated packaging
  • Fiber optic sensing and test/measurement systems
  • Laboratory optical path coupling platforms and precision optical equipment
