High RL >55dB Single Channel Fiber Array | 8 Degree APC Polish, Corning SMF-28e | Compact 2.5x2.5x7.9mm Quartz Block | Telecom Grade
High RL >55dB Single Channel Fiber Array | 8 Degree APC Polish, Corning SMF-28e | Compact 2.5x2.5x7.9mm Quartz Block | Telecom Grade
High RL >55dB Single Channel Fiber Array | 8 Degree APC Polish, Corning SMF-28e | Compact 2.5x2.5x7.9mm Quartz Block | Telecom Grade
High RL >55dB Single Channel Fiber Array | 8 Degree APC Polish, Corning SMF-28e | Compact 2.5x2.5x7.9mm Quartz Block | Telecom Grade
Specifications
Model Number :
910001701-06
Description
High RL >55dB Single Channel Fiber Array | 8 Degree APC Polish, Corning SMF-28e | Compact 2.5x2.5x7.9mm Quartz Block | Telecom Grade
Product Description

This 1CH SMFA is a single-channel, single-mode fiber array assembly designed for high-precision optical coupling and device packaging applications.

Key Features
Parameters Unit Spec. Value
Channel / 1 OK
Material / Quartz Glass OK
Channel Spacing μm 127 OK
Polishing Angle Degree A8° OK
Package(L)X(W)X(H) mm 2.5*2.5*7.9 OK
Insertion Loss dB ≤0.3



Fiber Type / SMF-28e OK
Fiber Tube mm 0.9 OK
Tube Color / White OK
Length m 1±0.1 OK
Connector / FC/APC OK
Operating Temperature (℃) 0～65 OK
Storage Temperature (℃) -40～85 OK
  • Single-channel, single-mode fiber array structure
  • Quartz Glass material
  • Corning SMF-28e fiber
  • A8° polished angle design
  • Channel spacing 127μm
  • Insertion loss ≤0.3dB
  • Return loss >55dB

High RL >55dB Single Channel Fiber Array | 8 Degree APC Polish, Corning SMF-28e | Compact 2.5x2.5x7.9mm Quartz Block | Telecom Grade

Applications
  • Optical device packaging
  • Optical chip and fiber coupling
  • Photonic Packaging
  • Fiber Interconnect
  • Laboratory precision optical path connection
  • Optical communication test platform
  • High-stability optical component integration
