STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
Specifications
MOQ :
1 piece
Operating Temperature :
-20°C to 70°C
Place of Origin :
China
Supply Ability :
5000000000 pieces/year
Display Type :
COB LCD Display
Display Mode :
STN
Color :
White display dot on blue background with white backlight
Interface :
16 Pin
Product Name :
STN LCD Module 20x4 Character LCD Display 2004a with Transmissive Negative Type
Controller :
ST7066U-0A
Operating Voltage :
5V
Brand Name :
Formike
Model Number :
WC2004A2SGW6B-B
Payment Terms :
T/T,L/C,Credit card,Cash
Dimensions :
98.0mm * 60.0mm * 14.2mm
Packaging Details :
Tray + Inner Box + Carton
Display format :
20character*4 line
Backlight :
LED
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Viewing Angle :
6 O'clock
Description

STN LCD Module 20x4 Character LCD Display 2004a with Transmissive Negative Type

LCD Name STN LCD Module 20x4 Character LCD Display 2004a with Transmissive Negative Type

Display Format

20character*4 line

Display Mode

STN (Blue), Negative, Transmissive

LCD Color

Display dot : White

Background: Blue

Active Area

70.4MIN(W) x20.8MIN(H)mm

Outline Dimension

98.0(W) x60(H) x 14.2MAX(T)mm

Viewing Area

76.0MIN(W) x25.8MIN(H)mm

Viewing Direction

6 O’clock

Pin NO.

16 Pin

Backlight

White

Driving Method

1/16 Duty, 1/5 Bias

Operating Temp.

 -20℃~+70℃

Storage Temp.

-30℃~+80℃

STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type

STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type

STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
STN LCD HD44780 Display LCD Module 20x4 Character 2004a With Transmissive Negative Type
