Specifications
Place of Origin :
China
Display Mode :
STN
MOQ :
1 piece
Display Format :
128*64 Dots
Operating Temperature :
-20°C to 70°C
Payment Terms :
T/T,L/C,Credit card,Cash
Packaging Details :
Tray + Inner Box + Carton
Backlight Color :
Usually Y-G or Blue or Gray
Display Type :
Graphic LCM
Viewing Angle :
6 O'clock
Interface :
20 Pin, 8-bit MPU interface
Model Number :
WG1206B1
Brand Name :
Formike
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Operating Voltage :
3.3V / 5V
Controller :
KS0107 & KS0108
Dimensions :
93mm * 70mm * 13mm
Supply Ability :
5000000000 pieces/year
Product Name :
128x64 Graphic LCD Screen Module 12864 Display With 20 Pin 8-BIT MPU Interface
Backlight :
LED
Description

128x64 Graphic LCD Screen Module 12864 Display With 20 Pin 8-BIT MPU Interface

3.3V 5V Graphic 128x64 LCD Display Screen Module 12864 20 Pin

Product Specification
LCD Name 128x64 Graphic LCD Screen Module 12864 Display With 20 Pin 8-BIT MPU Interface
Display Format

128*64 Dots
Module Size 93.0mm×70.0mm×13.0mm
View Area 70.7mm×38.8mm
Active Area 66.52mmx33.24mm
Dot Size 0.48mm×0.48mm
Dot Pitch 0.52mm×0.52mm
IC KS0107 &KS0108
Interface 20 Pin, 8-bit MPU interface enabled
Driving Method 1/64 Duty, 1/9 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WG1206B1SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WG1206B1SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WG1206B1SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WG1206B1SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WG1206B1SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WG1206B1SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
