Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Monel 400 1/2 Copper Fin Tube Embedded ASME SB163 NO4400 LL Type
Specifications
Brand Name :
YUHONG
Model Number :
L Type Fin Tube , LL Type Fin Tube , KLM Fin Tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 90 Days
Packaging Details :
Ply-Wooden Case
Base Tube Material :
Monel 400
Base Tube Standard :
ASME SB163 , ASTM B163
Type :
Wound, L type, LL Type, KL Type
Application :
Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type :
L Type Fin Tube , LL Type Fin Tube , KLM Fin Tube
Fin Material :
Aluminum , Copper , Stainless Steel , Carbon Steel
Description
Monel 400 ASME SB163 NO4400 Al 1060 Wound Fin Tube For Air Cooler & Heat Exchanger
Product Specifications
Attribute Value
Base Tube Material Monel 400
Base Tube Standard ASME SB163, ASTM B163
Type Wound, L type, LL Type, KL Type
Application Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type L Type Fin Tube, LL Type Fin Tube, KLM Fin Tube
Fin Material Aluminum, Copper, Stainless Steel, Carbon Steel
Product Description

Monel 400 is a nickel-copper alloy (approximately 67% Ni and 23% Cu) renowned for its exceptional corrosion resistance across diverse environments. This alloy offers excellent mechanical properties and can be fabricated through hot- and cold-working, machining, and welding processes.

The Monel 400 base tube combined with aluminum fins in a wound fin tube configuration creates an optimal solution for heat exchanger applications in demanding industries including marine, chemical processing, power generation, and aerospace. This combination delivers superior corrosion resistance from the Monel base with enhanced thermal conductivity from the aluminum fins.

Technical Specifications
Type Description Base tube O.D. (mm) Fin pitch Fin height Fin thick
Wound L / KL / LL Type Fin Tube 16-63 2.1-5 <17 ~0.4
Chemical Composition
Grade Ni Cu Fe Mn Si C S
Monel 400 63.0% min 28.0-34.0% 2.5% max 2.0% max 0.5% max 0.3% max 0.024% max
Mechanical Properties
Property Value
Tensile Strength 550-700 MPa (80,000-100,000 psi)
Yield Strength 240-345 MPa (35,000-50,000 psi)
Elongation 35% minimum in 50 mm
Hardness 65-75 HRB (Rockwell Hardness B)
Key Features
  • Enhanced Heat Transfer: Aluminum fins significantly increase surface area for improved heat transfer rates
  • Corrosion Resistance: Outstanding performance in marine and chemical environments
  • Mechanical Bonding: Wound fin design ensures secure attachment for efficient heat transfer
  • High Thermal Conductivity: Aluminum fins optimize heat exchanger efficiency
  • Durability: Monel 400 base provides exceptional resistance to mechanical stress
Applications

Marine and Offshore: Heat exchangers for seawater cooling and desalination plants

Chemical Processing: Equipment for acidic/alkaline environments and refinery applications

Power Generation: Plant coolers where corrosion resistance is critical

Aerospace and Defense: Heat exchangers requiring high temperature and corrosion resistance

Monel 400 1/2
