Specifications
Brand Name :
YUHONG
Payment Terms :
L/C, T/T
Model Number :
Wound Fin Tube , L Type fin tube
Certification :
ASME, PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Place of Origin :
China,Korea
MOQ :
1PC
Price :
1--10000 USD
Supply Ability :
10000 tons/month
Delivery Time :
5 - 30 Days
Packaging Details :
Ply wooden case
Base Tube Material :
Aluminum 1060
Base Tube Standard :
ASTM A179, ASME SA179
Type :
Wound, L type, LL Type, KL Type
Application :
Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type :
‘L’Type Fin Tube , ‘LL’Type Fin Tube , ‘KLM’Fin Tube
Fin Material :
Aluminum , Copper , Stainless Steel , Carbon Steel
Description
Wound Fin Tube, ASME SA179 With Aluminum 1060, L Type Fin Tube for Air Cooler and Condenser Applications
Product Specifications
Attribute Value
Base Tube Material Aluminum 1060
Base Tube Standard ASTM A179, ASME SA179
Type Wound, L type, LL Type, KL Type
Application Air cooler, Cooling Tower, Heat Exchanger, Condenser
Fin type L Type Fin Tube, LL Type Fin Tube, KLM Fin Tube
Fin Material Aluminum, Copper, Stainless Steel, Carbon Steel
Product Description

The L-Type Fin Tube is a specialized heat exchanger tube featuring fins attached in an L-shaped pattern on its outer surface. These aluminum or copper fins significantly enhance heat transfer efficiency between the internal fluid and surrounding environment.

Key Advantages
  • Increased surface area for superior heat transfer performance
  • L-shaped fins create beneficial airflow turbulence
  • Compact design reduces overall heat exchanger size and weight
  • Improved energy efficiency in thermal systems
  • Ideal for space-constrained applications requiring high heat transfer rates
Compact Condenser 15mm Finned Copper Pipe ASME SA179 In Thermal Systems Compact Condenser 15mm Finned Copper Pipe ASME SA179 In Thermal Systems
Material Specifications
Base Pipe/Tube Materials
  • Stainless Steel: ASME SA213/ASTM A213, ASME SA249/A249, ASME SA312/A312 (TP304, 304L, TP304H, TP310S, TP310H, TP316L, TP316H, TP316Ti, TP317, TP317L, TP321, TP321H, TP347, TP347H, TP904L)
  • Duplex/Super Duplex Steel: ASME SA789/A789, ASME SA790/A790 (S31803, S32205, S32750, S31500, S32304, S32900)
  • Carbon Steel: ASME SA106/ASTM A106 Gr B, Gr C, ASME SA179/ASTM A179, ASME SA192/ASTM A192, ASTM A214, ASTM A210 Gr.A1, Gr.C
  • Alloy Steel: Various grades including T1, T11, T12, T22, T23, T5, T9, T91, T92
  • Nickel Alloy: Hastelloy, Monel, Inconel, Incoloy, Pure Nickel, and Copper Alloy options available
Fin Materials

Available in Alloy Steel, Stainless Steel, and Carbon Steel options including High Frequency Welded fins, Extruded fins, and Serrated fin configurations.

Technical Specifications
Type Description Base Tube OD (mm) Fin Pitch (mm) Fin Height (mm) Fin Thickness (mm)
Wound L/KL/LL type fin tube 16-63 2.1-5 <17 ~0.4
Extruded Single metal combined metal 8-51 1.6-10 <17 0.2-0.4
Welding HF-welding fin tube 16-219 3-25 5-30 0.8-3
Production Capacity
  • Fin materials: All types available
  • Fins per meter: 50 to 500
  • Strip thickness: 0.4mm to 3.0mm
  • Production capacity: Over 5000 meters per day
  • Tube OD range: 15mm to 219.1mm
  • Lengths available: Up to 25 meters
Compact Condenser 15mm Finned Copper Pipe ASME SA179 In Thermal Systems
