P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
Specifications
Certification :
ASME , U STAMP , PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Brand Name :
YUHONG
Model Number :
Studded Tube, Pin Tube, Oil Furnace Tube , Steam Furnace Tube, Reforming Tube
Place of Origin :
China,Korea
MOQ :
1PC
Price :
1--10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 tons/month
Delivery Time :
5---75 days
Packaging Details :
Bundle + Cap , Ply wooden case
Base Pipe :
Alloy Steel Seamless Pipe: ASTM A335 P11, P12, P1, P22, P23, P5, P9, P91, P92
Stud material :
Carbon Steel, Stainless Steel 11Cr, 13Cr, ASTM A387 Gr.9
Welding Type :
High Frequency Welding
Fin Type :
Studded Tube, Pin Tube, Oil Furnace Tube , Steam Furnace Tube, Reforming Tube
Stud Hight :
8mm~ 50.8mm
Stud Diameter :
12.7mm, 15.88mm, 19.05mm , 25.4mm
Description
ASTM A335 P11 Alloy Steel Seamless Pipe with 11Cr Studded Tube
Product Specifications
Attribute Value
Base Pipe Alloy Steel Seamless Pipe: ASTM A335 P11, P12, P1, P22, P23, P5, P9, P91, P92
Stud material Carbon Steel, Stainless Steel 11Cr, 13Cr, ASTM A387 Gr.9
Welding Type High Frequency Welding
Fin Type Studded Tube, Pin Tube, Oil Furnace Tube, Steam Furnace Tube, Reforming Tube
Stud Height 8mm~50.8mm
Stud Diameter 12.7mm, 15.88mm, 19.05mm, 25.4mm
Product Overview

Yuhong Holding Group brings over 35 years of experience in pipeline products manufacturing, operating three joint venture factories spanning more than 130,000 square meters. With 600 skilled workers and 106 production lines, we provide exceptional support to our clients.

Certifications

ABS, LR, DNV-GL, BV, KR, CCS, ASME, ISO 9001, ISO 14001, ISO 18001

Manufacturing Process

Studs are fully automatically welded onto the tube by resistance welding for consistent quality and performance.

Delivery Conditions

Tube ends are square cut, free of burrs, internally dried and air blown clean, with external varnish coating at both ends.

Surface Protection

Oil dip, black coating or varnish options available.

Stud Types

Cylindrical or elliptical configurations available.

Material Specifications
Items General Materials Popular ASTM/ASME Materials
Core Tube Material Carbon Steel, Alloy Steel, Heat Resistant Steel, Stainless Steel 1. Carbon Steel: A106 Gr.B
2. Stainless Steel: TP304/304L, TP316/TP316L, TP347, TP321, TP347
3. Alloy Steel: P5, T5, P9, T9, T11, T22
Studs Material Carbon Steel, Stainless Steel 1. Carbon Steel
2. Stainless Steel: TP409/410, TP304/304L, TP316/TP316L, TP321/TP310S
Dimensions
Parameter Specification
Tube OD (mm) 38mm~219mm
Tube Wall Thickness (mm) 4mm~15mm
Tube Length (mm) 16,000mm Max.
Studs OD (mm) 6mm~16mm
Studs Height (mm) 10mm~45mm
Studs Type Circular, elliptical, waist drum type
Product Line
Main Alloy Steel Studded Tubes
  • ASTM A335 P11 Studded Tube
  • ASTM A335 P22 Studded Tube
  • ASTM A335 P5 Studded Tube
  • ASTM A335 P9 Studded Tube
  • ASTM A335 P91 Studded Tube
Applications
  • Furnace and Fired Heaters
  • Chemical Industry
  • Petrochemical Industry
  • Power Stations
P11 Alloy Steel Stainless Steel Finned Studded Tube Pipe For Fired Heater Oil Refinary
For more detailed specifications or custom requirements, please contact our sales team.
