Specifications
Brand Name :
YUHONG
Model Number :
ASTM A213 T9
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
CHINA
MOQ :
Depend the size of finned tubes, 50-100PC
Price :
10-10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
500 tons/month
Delivery Time :
30-60 days
Packaging Details :
Ply-wooden Case With Iron Frame
Product :
Fin Tubes or Finned Tube
Type :
Studded Tubes
Standard :
ASTM A213
Material :
T9 Base Tubes and CS Fins
Length :
10300MM For This Order
Other Details :
Base Tube: 141.3×Min 5.7 MM; Fin O.D. 12.7MM, Fin Height 25.4MM; 18 Studs/Circle
Packing :
Ply-wooden Case With Iron Frame
Use :
For large equipment, Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc
Description
Heat Exchanger Studded Tubes ASTM A213 T9 Alloy Seamless Tube
Product Specifications
Attribute Value
Product Fin Tubes or Finned Tube
Type Studded Tubes
Standard ASTM A213
Material T9 Base Tubes and CS Fins
Length 10300MM For This Order
Other Details Base Tube: 141.3×Min 5.7 MM; Fin O.D. 12.7MM, Fin Height 25.4MM; 18 Studs/Circle
Packing Ply-wooden Case With Iron Frame
Use For large equipment, Heat Exchanger / Boiler / Furnaces / Condensers / Evaporators, etc
Chemical Composition (%)
Grade C Mn P S Si Cr Mo Ni V
T9 0.15 0.30-0.60 0.025 0.025 0.025-1.00 8.00-10.00 0.90-1.10 ... ...
Mechanical Properties
Grade Tensile Strength,min Yield Strength (0.2%Offset,min)
T9 60ksi (415 MPa) 30ksi (205 MPa)
Key Advantages
  • Excellent mechanical properties and resistance to oxidation and corrosion
  • Withstands temperatures up to 650°C (1200°F) while maintaining structural integrity
  • Chromium content provides superior oxidation resistance in high-temperature environments
  • Resistant to sulfur-containing environments and other corrosive media
  • High tensile strength and creep resistance for demanding applications
  • Allows for thinner tube walls, improving heat transfer efficiency
Product Definition
Studded tubes are heat exchanger tubes featuring small welded studs or pins on their outer surface. These studs significantly increase surface area, enhancing heat transfer efficiency when exchanging heat between the tube and surrounding medium (gases or fluids).
Common materials include carbon steel for general applications, stainless steel for corrosive environments, and alloy steels (T9, T11, T12) for high-temperature, high-pressure applications.
Applications
  • Petrochemical and Refining Industries - Processing high-temperature fluids and gases
  • Industrial Heating Systems - Thermal oil heaters and steam generators
  • Power Plants - Economizers, air preheaters, and superheaters
  • Marine and Offshore Applications - Heat exchangers for marine equipment
  • Waste Heat Recovery Systems - Boilers, furnaces, and exhaust systems
