Specifications
Brand Name :
YUHONG
Model Number :
Monel 400 Fin tube , Copper Nickel Fin Tube
Certification :
ASME ,PED, API , ABS, LR, DNV, GL , BV, KR, TS, CCS
Place of Origin :
China,Korea
MOQ :
1PC
Price :
1--10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 tons/month
Delivery Time :
5---75 days
Packaging Details :
Ply wooden case
Base Tube Standard :
ASTM B163, ASME SB163 , ASTM B165, ASME SB165
Base Tube Grade :
Monel 400, Alloy 400, UNS NO4400, 2.4360
Fin Material :
ASME SB208 GR. 1060 , GR.1100
Fin Type :
Embedded G Type Fin tube
Testing of Fin tube :
Pressure Testing , Firmness testing , Pulling Testing
Application :
Air cooler, cooling Tower , oil refininging
Description
Embedded G Fin Tube, ASTM B163 Monel 400 Copper Nickel Seamless Tube with Al 1060 for Oil Refining Projects
Product Specifications
Attribute Value
Base Tube Standard ASTM B163, ASME SB163, ASTM B165, ASME SB165
Base Tube Grade Monel 400, Alloy 400, UNS NO4400, 2.4360
Fin Material ASME SB208 GR. 1060, GR.1100
Fin Type Embedded G Type Fin tube
Testing Pressure Testing, Firmness testing, Pulling Testing
Application Air cooler, Cooling Tower, Oil refining
Product Description

Yuhong produces ASME SB163/ASTM UNS N04400 Monel 400 G Type Finned Tubes. Monel 400 is a nickel-copper alloy renowned for its excellent corrosion resistance, particularly in marine and chemical environments. These tubes are widely used in various industrial applications due to their unique properties.

ASME SB163 UNS N04400 Monel 400 tube is a Nickel Base Alloy Seamless Tube designed for heating applications. The alloy maintains excellent mechanical properties at both high temperatures (up to 1000°F) and subzero temperatures.

Monel 400 is hardened by cold working only and offers exceptional resistance to stress corrosion cracking in most freshwaters. Its corrosion-resistant properties make it ideal for marine applications and flowing seawater environments.

Chemical Composition (ALLOY 400/UNS N04400)
C MN P S Si Cr Ni Cu Al Fe
.25max 1.5 max - .01 max .5 max - 63.0 min 27-33 2.30-3.15 2.5 max
Product Specifications
Product Form Specification
Monel 400 Sheet/Plate QQ N 286
Monel 400 Round Bar ASME SB-865 AMS 4676 QQ N 286
Monel 400 Pipe B165
Monel 400 Tube B163, B165
Monel 400 Fittings B366
Monel 400 Forgings QQ N 286 AMS 4676
Fin Tube Specifications
Type Description Base Tube O.D. (mm) Fin Pitch (mm) Fin Height (mm) Fin Thickness (mm)
Embedded G-type fin tube 16-63 2.1-5 <17 ~0.4
Extruded Single metal combined metal 8-51 1.6-10 <17 0.2-0.4
Low fin tube T-type fin tube 10-38 0.6-2 <1.6 ~0.3

Production Capacity: More than 5000 meters per day
Available Lengths: Up to 25 meters
Tube Material Options: All types of material with minimum thickness of 1.00mm
