Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Compact Embedded Spiral Micro Fin Tube Aluminum 1100 A213 T5
Specifications
Brand Name :
YuHong
Model Number :
ASTM A213 T5
Certification :
ABS, BV, ISO, ASTM, SGS
Place of Origin :
China
MOQ :
200~500 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C AT SIGHT
Supply Ability :
According to Clients' requirements
Delivery Time :
35-60 Days (Depend on Customer's Requirements)
Packaging Details :
Ply-wooden Cases with Steel Frames and Pipe's both ends with plastic caps
Product Name :
Embedded/G Type Finned Tube
Base Tube Specification&Material :
ASTM A213 T5
Fin material :
ASTM B209 AL-1100
Fin Height :
＜17mm
Fin Thickness :
~0.4mm
Base Tube OD :
16~63mm
Fin Pitch :
2.1~5mm
Application :
Boiler/Air-cooled Condenser/Heat Exchanger
Description
A213 T5 Embedded Fin Tube With Aluminum 1100 Fins For Oil Refineries
Product Specifications
Attribute Value
Product Name Embedded/G Type Finned Tube
Base Tube Specification & Material ASTM A213 T5
Fin material ASTM B209 AL-1100
Fin Height <17mm
Fin Thickness ~0.4mm
Base Tube OD 16~63mm
Fin Pitch 2.1~5mm
Application Boiler/Air-cooled Condenser/Heat Exchanger
Product Overview

ASTM A213 T5 Embedded Finned Tube with Aluminum 1100 fins is a high-performance heat exchanger component designed for oil refineries and other demanding industrial applications. These tubes feature fins embedded into the tube wall to significantly increase heat transfer surface area while maintaining mechanical stability.

Key Features and Benefits
  • Enhanced Heat Transfer: Embedded fins increase surface area for faster, more efficient thermal exchange
  • Mechanical Stability: Corrugated pattern resists damage during installation and operation
  • Compact Design: Ideal for space-constrained applications
  • Customizable Configuration: Fin shape, size, and material can be tailored to specific requirements
  • Corrosion Resistance: ASTM A213 T5 alloy steel provides excellent durability in harsh environments
  • Long Service Life: High-quality materials and manufacturing ensure extended operational lifespan
Technical Specifications

Chemical Composition: Carbon (C): 0.15% max, Manganese (Mn): 0.30-0.60%, Phosphorus (P): 0.025% max, Sulfur (S): 0.025% max, Silicon (Si): 0.50-1.00%, Chromium (Cr): 4.00-6.00%, Molybdenum (Mo): 0.45-0.65%

Mechanical Properties: Tensile Strength: 415MPa min, Yield Strength: 205MPa min, Elongation: 30% min, Hardness (HRB): 85 max

Industrial Applications
  • Power generation plants for efficient heat transfer in boilers
  • Petrochemical processing and refining equipment
  • Chemical and pharmaceutical manufacturing systems
  • HVAC/R systems for enhanced thermal performance
  • Food processing for pasteurization and sterilization
