780-1650PM fiber optic patch cable Fibre Patch Leads For Aerospace Communications Equipment
780-1650PM fiber optic patch cable Fibre Patch Leads For Aerospace Communications Equipment
780-1650PM fiber optic patch cable Fibre Patch Leads For Aerospace Communications Equipment
780-1650PM fiber optic patch cable Fibre Patch Leads For Aerospace Communications Equipment
Specifications
Brand Name :
Liocrebif
Model Number :
LKF-780-1650PM Fiber Optic Patch Cords
Certification :
GJB 9001C-2017
Place of Origin :
China
MOQ :
1
Price :
5000-25000CHY
Payment Terms :
T/T
Supply Ability :
10000
Delivery Time :
2-4 weeks
Packaging Details :
Wooden box/Cardboard box/Container
Color&Classification :
LKF-780-1650PM Fiber Optic Patch Cords
Brand :
Liocrebif
Output format :
RS422
Application :
Related optical detection and applications. Fiber optic sensing systems. Medical detection equipment. Aviation and aerospace communications equipment
Original Place :
China
Dimension :
Determined by model
Description
Essential details
MOQ:1
Specification Number:LKF-780-1650PM Fiber Optic Patch Cords
Product Introduction

Polarization-maintaining fiber patch cords (tail fibers) are fiber optic connectors featuring standard fiber optic connectors at one or both ends. They are manufactured using polarization-maintaining fibers with precise stress axis alignment to create fiber patch cords (tail fibers). Our polarization-maintaining fiber patch cords utilize imported polarization-maintaining fiber optic connectors, offering low loss, high extinction ratio, and low return loss. We also provide optical fiber end-face AR coating upon customer request to optimize fiber-to-free-space coupling.

Table1 780-1650PM Fiber Optoc Patch Cords Main Parameters

Category

Indicator Requirements

Unit

Center Wavelength

780nm
850nm

980nm
1060nm
1064nm

1310nm
1550nm
1650nm

nm

Connector Type

FC/SC/LC or customized

/

Insertion Loss

≤1.0

≤0.8

≤0.5

dB

Return Loss

＞50(PC),＞60(APC)

dB

Extinction Ratio

≥23

dB

Interchangeability

≤0.2

dB

Repeatability

≤0.2

dB

Mating Cycles

＞1000

time

Fiber Type

PM850 fiber

PM980 fiber

PM1310 fiber
PM1550 fiber

/

Power Handling (CW)

300

mW

Tensile Load

≥5 (0.9 optical cable), ≥50 (3.0 optical cable)

N

Operating Temperature

-20~+85

C

Main Features

Covers multiple communication wavelengths including 780nm, 850nm, 980nm, 1064nm, 1310nm, 1550nm, and 1650nm.

Connectors utilize imported connector components, featuring low loss and high extinction ratio.

Offers fast-axis, slow-axis, and custom-angle alignment to meet diverse customer requirements.

Connectors available in FC, SC, LC, and other models, with support for non-standard (steel-jacketed pins) polarization-maintaining end customization.

Fiber end-face finishes include PC, UPC, APC, or custom grinding angles.

Applications

Related optical detection and applications

Fiber optic sensing systems

Medical detection equipment

Aviation and aerospace communications equipment
