Specifications
Brand Name :
Matsumoto
Model Number :
TCK46
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
13800-16500
Payment Terms :
T/T
Delivery Time :
30 working days
Packaging Details :
plywood case
Spindlespeed :
Max 4000 RPM
Controlsystem :
Fanuc/GSK/Mitsubishi
Condition :
New
Precision :
High precision
Key Words :
Slant Bed CNC Lathe Machine
Max.swing over bed :
450mm
Description

TCK46 High Precision Efficient Tck46 Slant Lathe Machine with Quick Servo Turrets


Description:

The TCK46 Slant Bed CNC Lathe is a high-performance, precision-engineered turning center designed for the efficient machining of complex, medium-sized components. It features a robust 45° inclined bed cast from high-strength Meehanite resin sand cast iron (HT300), providing exceptional structural rigidity and vibration damping.


PROJECT UNIT TCK46
Processing range Max.swing over bed mm 450

Max.processing diameter(axis/chuck) mm 200/400

Max.processing length mm 400

Max.bar diameter mm 46
Travel X axis travel mm 200

Z axis travel mm 530
Spindle Output power kw 7.5/11

Spindle end form / A2-5

Spindle speed r/min 35-4000

Spindle bore mm 56
Chuck 3-jaw chuck 8-inch hollow
Tail stock Tail stock sleeve diameter/travel mm 300

Tail stock sleeve taper hole Morse 5
Guide rail screw Guide rail specification mm P-level RG35

Screw specification mm 3210
Speed Fast moving speed(X/Z) m/min 25

Cutting feed speed mm/min 1-8000
Tool post Tool post form / Servo turret

Blade size mm 25

Tool capacity set 8

Max.boring tool diameter mm 32
Machine accuracy Positioning accuracy(X axis) mm 0.008

Positioning accuracy(Z axis) mm 0.013

Repeat positioning accuracy(X axis) mm 0.005

Repeat positioning accuracy(Z axis) mm 0.006
Others CNC control system / GSK(980TB3i)

Volume of cutting fluid tank L 60(independent)

Overall dimension mm 2200*1450*1760
(Manual chip removal)

Gross weight kg 3000


Application:

The TCK46 is a versatile CNC lathe ideal for high-volume, high-precision production of shaft-type and disc-type workpieces across numerous industries.
