Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
Specifications
Springs :
EN 2.4819 (Alloy C-276)
Faces :
CB, TC, SSC
Elastomers :
FKM, EPDM, FEPM, FFKM
Notes :
Seal pressure capabilities are dependent on the fluid sealed, temperature, speed, and seal face combinations. For operation outside the limits and additional materials consult BESTSEAL.
Standards and Approvals :
ISO-3069C, ASME B73.1, ASME B73.2, NSF61
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
MOQ :
1pc
Metals :
EN 1.4401 (316SS), Other Metallurgies available on request
Pressure :
711 mm (28") Hg Vacuum – 40 bar g (600 psig)
Packaging Details :
Carton
Temperature :
-55 to 300 °C (-67 to 570 °F)
Brand Name :
BESTSEAL
Model Number :
Chesterton 180
Speed :
25 m/s ( 5000 fpm )
Certification :
ISO9001
Size Range :
25 mm to 120 mm (1.000 inch to 4.750 inch)
Delivery Time :
15 working days
Supply Ability :
1000000/Month
Place of Origin :
CHINA
Description
Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
  • Mechanical Seals
  • Cartridge Seals
180

Heavy Duty Single Cartridge Seal

A single cartridge design for maximum reliability in demanding applications.

Product Features
  • Maximum performance for demanding, high-torque applications
  • Reliable sealing of slurries
Technical Data
Size Range 25 mm to 120 mm (1.000 inch to 4.750 inch)
Standards and Approvals ISO-3069C, ASME B73.1, ASME B73.2, NSF61
Materials
Faces CB, TC, SSC
Elastomers FKM, EPDM, FEPM, FFKM
Metals EN 1.4401 (316SS), Other Metallurgies available on request
Springs EN 2.4819 (Alloy C-276)
Operating Conditions
Temperature -55 to 300 °C (-67 to 570 °F)
Speed 25 m/s ( 5000 fpm )
Pressure

711 mm (28") Hg Vacuum – 40 bar g (600 psig)
Notes Seal pressure capabilities are dependent on the fluid sealed, temperature, speed, and seal face combinations. For operation outside the limits and additional materials consult BESTSEAL.

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump

Chesterton 180 Heavy Duty Single Cartridge Mechanical Seal for Slurry Pump
