Specifications
Brand Name :
ACEY
Model Number :
ACEY-AS11S
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
USD 6450~8600/Set
External dimension :
Length1430* width660* height1350mm
Battery type :
18650（other sizes available）
Receiving channel :
10 sorting & matching group channels, 1 unqualified product channel, available arbitrary set for each channel's sorting value.
Working power :
Single-phase ~220V±10%/50Hz±10%, power <800W
Test parameters :
AC internal resistance, DC voltage
Sorting speed :
80ppm
Packaging Details :
Plywood Case
Payment Terms :
T/T,PayPal,L/C,Western Union,MoneyGram
Supply Ability :
200 Sets/Month
Warranty :
1 Year Warranty With Lifetime Support
After-sales Service :
24/7 Technical Support
Delivery Time :
7~35 Days
Description

11 Channels Lithium Cell Automatic Sorter and Tester with PC for Cylindrical Cell

Product Description

ACEY-AS11S can automatically sort the batteries according to the specified requirements, and has the characteristics of rapid and accurate sorting with barcode scanner can read and record each cell correctly. Auto sorting machine fundamentally avoids unreliable factors such as human misoperation and misclassification in the battery sorting process, and improves the quality and efficiency of battery sorting. It is suitable for automatic sorting of large and medium-sized cylinders batteries.

Product Features

*Automatically sort the voltage and internal resistance of cylindrical batteries like 18650, 26650
*High precision and fast speed,High degree of automation, high productivity
*Touch screen operation, easy and fast responding.
*The process detection signal is comprehensive and diverse, ensuring sufficient maturity and reliability
*Humanized processing of subtle links greatly guarantees the safety of operators and products
*Replace sorting mold to sort different size battery cell(Moulds need to be purchased extra)
*With computer

Main Technical Parameter

Voltage Supply Single-phase ~220V±10%/50Hz±10%, power <800W
Battery Types 18650(other sizes available)
Receiving channel 10 sorting & matching group channels, 1 unqualified product channel, available arbitrary set for each channel's sorting value.
Test parameters AC internal resistance, DC voltage
Internal resistance test Test range: 80mΩ,
Accuracy: ±0.5%rdg
Display resolution: 0.01mΩ
Voltage test Test range: 8V
Accuracy :±0.015%rdg,
Display resolution: 0.01mV
Sorting speed 80ppm
AI.Set function Intelligent one-button setting, specially designed for new functions of battery pack.
Size L1430mm*W660mm*H1350mm
Weight <200Kg

Product Display

11 Channel Lithium Battery Sorting Machine Sorter For Cylindrical Cell

11 Channel Lithium Battery Sorting Machine Sorter For Cylindrical Cell11 Channel Lithium Battery Sorting Machine Sorter For Cylindrical Cell11 Channel Lithium Battery Sorting Machine Sorter For Cylindrical Cell
